Rock Slide Instruction RSEI 121
6. The rubber strip can be customized. The entire strip can be put on the edge or cut
the rubber into put smaller pieces on if you don’t want the fit to be as tight. The
strip is pushed onto the edge of the metal
Rubber strip installed
7. The table is folded up by folding in this order:
a. Bottom table is folded in half and put at the back
b. Fold right arm in against bottom table
c. Fold left arm in against right arm
d. Fold top table down
e. Rotate capture pins clockwise until they push in to lock table together
8. To open the table, turn capture pins counterclockwise and pull out. Fold table out in
this order:
a. Lift table top up
b. Pull left arm out
c. Pull right arm out
d. Fold bottom table out and click table surface into the slots on both arms
Rubber strip
Front edge of bottom
table surface
