Rock-Slide Engineering JK2 SLIDER - Manual

JK2 SLIDER INSTALLATION
SL-2D-100-JK
Slider Installation
1. Remove the stock rocker guard if equipped.
2. Hold the slider temporarily into the position you would like it on the Jeep.
a. You may want some help so that you can support the weight of the slider
3. Make sure the slider is in the position desired and ensure it will not interfere with
front or rear wheel wells.
4. When the slider is in the desired position, carefully mark the 6 holes on the side of the
Jeep that will be required for mounting the slider.
a. **It is extremely important these holes are marked precisely to insure the
slider will fit properly once the nutserts have been installed
b. Double check to make sure the top side of the slider is at flat 90 degree angle
5. Remove the slider and drill a 7/16” pilot hole in the marked locations.
