Blaupunkt DM2000 - Manual (Page 7)

E-6
ENGLISH
FRANÇAIS
ESP
AÑOL
POR
TUGUÊS L-ch Level meter R-ch Level meter
Storing the station names
You can assign a name to each radio station and store it in
memory. As much as 30 station names can be stored com-
posed with 8 characters each.
Storing the station names
1.
Tune in a station whose name you want to store.
2. Press the DISP for more than 2 seconds.
The “ NAME EDT ” will light then the “ _ _ _ _ _ _ _ _ ” on
the display window. The first “ _ ” flashes.
3. Enter the characters.
A. Rotate the dial in a clockwise direction to select the
desired characters.
( A
➜ B ➜ C ➜ . . . Z ➜ < ➜ > ➜ ∗ ➜ + ➜
′
➜ − ➜ ′ ➜ /
➜ 0 ➜ 1 ➜ 2 ➜ 3...9 ➜ “ ”Space )
B. Press the TUN/ TRK to move the flashing cursor to the
next position. If you press TUN/ TRK , the flashing cur-
sor moves to the left.
C. Repeat steps A. and B. to complete entering the entire
name 8 characters max.
Tip
To erase/correct a name, press the
DISP for more than 2
seconds to clear the character and re-enter.
4.
Press the MUTE / SENS to store the station name.
The station name flashes.
5. To return to the normal radio reception, Press DISP .
Erasing the station names
1.
Tune in any station and press the DISP for more than 2
seconds.
2.
Press the MUTE / SENS .
The station name or “ _ _ _ _ _ _ _ _ ” flashing.
3. Rotate the dial to select the name of the station that you
want to erase. To erase all the names of the stations, dis-
play “
✳ ALL DEL ”.
4. Press the DISP for more than 2 seconds.
Repeat steps 3. and 4. if you want to erase other names.
5.
To return to the normal radio reception, Press DISP .
Direct Access to Memorized Stations via
Station call
You can search for the memorized AM & FM station names in
the memory.
1. Press the DISP to display the “ STN CALL ” on the dis-
play window.
2. Rotate the large dial to select the desired station name.
3. Press the MUTE / SENS to tune in the desired station.
Level Meter selection
The meter displays can be selected from four types.
You can select :
• METER 1
: The level meter goes upward.
• METER 2 : Only the very top segment lights.
• METER 3 : The remaining segments light. (opposite of
METER 2)
• METER 4 : The level meter goes up and down dividing
from the center segment.
• METER 0 : No meter is indicated.
1.
Press the DISP to display the “ METER 1 ” on the display
window.
2.
Rotate the dial in a clockwise direction to select the de-
sired meter indication.
METER 1 ➜ METER 2 ➜ METER 3 ➜ METER 4 ➜ ME-
TER 0
Level Meter Sensitivity selection
The sensitivity of the level meter display can be switched.
You can select :
• LEVEL 1 : Normal sensitivity.
• LEVEL 2 : High sensitivity.
1.
Press the DISP to display the “ LEVEL 1 ” on the display
window.
2. Rotate the dial to select the desired meter sensitivity.
Enhancing the bass sound
For extended bass centered @ 72Hz, Blaupunkt’s XBASS
function can be set for either each band and CD mode.
You can select :
• XBASS 1 : Enhanced BASS level (low).
• XBASS 2 : Enhanced BASS level (Middle).
• XBASS 3 : Enhanced BASS level (High).
• XBASS 4 : Enhanced BASS level (Very high).
• XBASS 0 : No BASS enhanced.
Press the XBASS repeatedly to select the bass sound.
“ ” appears on the display window.
Each time you press XBASS , the current mode appears on
the display window and the mode change as follows:
XBASS 0 ➜ XBASS 1 ➜ XBASS 2 ➜ XBASS 3 ➜ XBASS 4
Note
Reduce XBASS levels if your combination of speakers and add-
on amplifiers sound distorted at the preferred sound level.
LEVEL 1
LEVEL 2
Key Largo (Eng) p.1-13 6/19/00, 10:02 AM 6
