13
PureFlow AirDog
AirDog
®
II Dodge 1998 ½ - 2004
Section 5-C High Flow Suction Tube
INSTALLING THE AIRDOG
®
HIGH FLOW SUCTION TUBE
The AirDog
®
II DF-200 includes a ½” High Flow suction tube to accommodate the high flows of
this system. To install the ½ suction tube it is necessary to either drop the fuel tank or to lift the
truck bed.
NOTE: Should you choose to drop the fuel tank, support the tank as it is when it is installed on
the truck. If you let it rest flat on the floor, the tank may squash out and the suction tube will be
too short after the tank is re-installed in the truck. The suction tube, being cut too short may suck
air as the fuel drops below ¼ tank level.
NOTE: Should you choose to pull the pickup bed to access the tank. Be sure to disconnect the
tail light wires, fuel tank filler tube, and any other accessories or components that may be
secured to the frame and bed.
When Dropping the Tank, Always Remember Safety First!
Figure 19
Figure 20
Figure 21
If you choose to remove the bed, properly support the truck bed to prevent
serious injury or death!
Figure 22 Figure 23
