ASSEMBLY SEQUENCE FOR WINCH BUMPER.
13.
1. Remove the four solenoids from the base of the
control box using the copper bus bar as an aid and
hold to one side.
14.
Before
1. Remove the two bolts in the base of the control box
and reposition them into the more centralised holes
After
15.
1. Place the 4 solenoids over the 2 metal stands that
are facing upwards. Make sure they line up with the
holes in the base.
