FITTING KIT No. 6171387, 6171391, 6171364
USE
PART No
QTY
DESCRIPTION
BUFFER FITTMENT
6151128
17
NUT FLANGE M6
3162158
1
BUFFER LOWER
3162153
1
BUFFER LHS
3162154
1
BUFFER RHS
LIGHT SURROUNDS TO BAR
3162156
1
LIGHT SURROUND LHS
3162157
1
LIGHT SURROUND RHS
CHROME TUBE FITTMENT
6151255
2
BOLT M12 X 40mm
4581049
2
WASHER FLAT M12
4581050
2
WASHER SPRING M12
6131174
1
CHROME TUBE
MOUNT ASSY TO VEHICLE
3751859L
1
BRACKET IMPACT ABSORBER LHS
3751859R
1
BRACKET IMPACT ABSORBER RHS
4581011
2
WASHER FLAT 27x12x4mm
WING BRACE
BAR TO VEHICLE
3756195L
3756195R
1
1
BRACE WING
BRACE WING
6151256
2
BOLT M6 BUTTON HEAD S/STEEL
4581072
2
WASHER M6 x 19mm
6151017
2
BOLT M6 x 16mm HEX HEAD
6151128
4
NUT M6 FLANGE
4581072
2
WASHER 19x7x1.6mm
WINCH
4581044
4
WASHER 3/8”
CONTROL BOX FITMENT
3756220
1
CONTROL BOX BRACKET
6151017
2
BOLT M6 X 16MM
6151128
4
NUT FLANGE M6
WINCH COVER FITTMENT
6151128
2
NUT FLANGE M6
6151256
2
SCREW M6 S/STEEL BUTTON HEAD
6191001
1
WINCH COVER EXTRUSION
6521031
1
WINCH COVER
4581035
2
WASHER M6
RUBBER EXTRUSION FITMENT
6821116
14
SQUARE PLASTIC PLUG
6151176
14
SCREW SELF TAPPING 12mm 8G
6191002
2
EXTRUSION
3193649
2
MOUNT STRIPS
WINCH BUMPER TO MOUNT
ASSEMBLY
6151255
6
BOLT M12 X 40mm
4581050
6
WASHER SPRING M12
4581007
6
WASHER FLAT M12 LARGE
CB
3162152
2
PLASTIC PLUG DIA16
ROLLER FAIRLEAD FITTMENT
4581049
4
WASHER FLAT M12
NUMBER PLATE FITTMENT
6151017
2
BOLT M6 X 16mm
6151128
2
NUT FLANGE M6
6781408
1
TAPE DOUBLE SIDED
WIRING
180302
10
CABLE TIE
