FITTING PROCEDURE BAR ON VEHICLE
51. Note that the aperture moldings are handed
(RH or LH), select correct hand for each wing
aperture. Apply Sikaflex to recess in aperture
molding flange then fit to aperture in wing.
Use adhesive tape to secure plastic mold
while Sikaflex cures.
52. Use adhesive tape to secure plastic mold
while Sikaflex cures.
53. Wire up indicators and running lamps. Wire
loom extensions are supplied in fitting kit.
54. If winch fitted, fit off winch hook.
