User Guide TECHNICAL DATA
MGP D5 53
RS-232 in RS-232 out
9 PIN DSUB FEMALE
1 NC
2 RXD
3 TXD
4 NC
5 GND
6 NC
7 NC
8 NC
9 PIN DSUB MALE
1 NC
2 TXD
3 RXD
4 NC
5 GND
6 NC
7 NC
8 NC
Audio out RC in
Black
3.5 mm mini jack
TIP: R
STIM: L
RING: GND
3.5 mm stereo mini jack
TIP: 5V DC
RING: SIGNAL
STEM: GND
Audio in 1 Audio in 1
Black
3.5 mm mini jack
TIP: R
STIM: L
RING: GND
Black
3.5 mm mini jack
TIP: R
STIM: L
RING: GND
USB LAN
DIGITAL USB
1 VCC
2 -Data
3 +Data
4 GND
1 TX+
2 TX-
3 RX+
4 GND
5 GND
6 RX-
7 GND
8 GND
