1.9 Calibration
Don’t Perform Calibrate Until You Really Understand.
Calibration Requirement for I-7011/11D/11P/11PD/18/18P
Notification :
1
While calibrate type 06, need connect external shunt resistor,
125 ohms, 0.1% (Ref Sec.1.5).
2
Connect calibration voltage(or current) signal to module’s
input. For I-7018/18P, connect to channel 0. (Wire connect ref
Sec.1.5)
3
Before calibration, warm-up module about 30 minutes for bet-
ter accuracy.
Example Calibration Sequence for Type 00 :
1
Setting Type to 00
->
Ref
Sec.2.1.
2
Enable Calibration
->
Ref
Sec.2.20.
3
Apply Zero Calibration Voltage (0mV)
4
Preform Zero Calibration Command
-> Ref Sec.2.6.
5
Apply Span Calibration Voltage (15mV)
6
Perform Span Calibration Command
-> Ref Sec.2.5.
7
Repeat step1 to step6 three times.
Calibration sequence for other type is similiar but different in step
1 to set different type.
Type Code
00
01
02
03
04
05
06
Min. Input
0 mV
0 mV
0 mV
0 mV
0 V
0 V
0 mA
Max Input
+15
mV
+50
mV
+100
mV
+500
mV
+1 V
+2.5 V
+20
mA
