Panels
A panel defines the rectangular area of your ProntoPro’s touch screen
between the system area at the top of the touch screen and the bar at the
bottom of the touch screen.
A panel consists of up to 255 frames or buttons. Every frame can contain up
to 255 frames or buttons.
Frames are inactive user interface elements. They contain a background
color or a bitmap, and a name. Frames can be tapped, but they never
contain an action. Frames are primarely used for grouping buttons and
other frames.
Buttons are active user interface elements. They contain a background
color or a bitmap for each of four different states, and a name. A button
can contain an action that is executed when you tap it.
An action can be a delay, an IR code, or an alias (a shortcut) to another
action list (see “ Programming ” on p. 49 for more details)
An action list is a list of up to 255 actions. The last action to execute
can be a jump to a specific panel.
Button:
containing an action
Button:
not containing an action
Frame
Panel
