13

Probe Boxes:
1. Disconnect the signal cable from the probe boxes.
2. Remove probe box from CDS hopper.
3. Place the switch on the probe box in the “HIGH”

position.

4. Check the resistance across the box cable pins,

see Fig. 10.

5. With the probe box switch in the “LOW” position

check the resistance across the pins, refer to Fig.
10.

6. If readings match the values indicated, the probe

system is functioning properly.

Switch Removal and Replacement:
1. Remove the #6 thread cutting screw securing the

probe housing cover to the probe housing.

2. Remove the wires from the switch terminals.
3. Compress the clips inside the probe box and

gently push the switch through the opening

4. Push the new switch into the opening and spread

the clips to hold switch in the autofill box.

5. Refer to Fig. 11 when reconnecting the wires.

1

4

2

3

AFPO-2

AFPO-2

300

600

300

1

4

2

3

AFPO-3

AFPO-3

300

600

600

300

FIG. 8 PROBE SWITCHES

SERVICE (cont.)

Location

The probe switches are located on the rear of each

hopper, mounted in the probe housing cover.

Test Procedure
Probe System
1. Disconnect the dispenser from the power source.
2. With the probe boxes connected to the signal

cable, remove connector from refill box.

3. Place the switch on the probe box in the “HIGH”

position.

4. Check resistance across pins as shown in Fig. 9.

FIG. 11 PROBE LOW/OFF/HIGH SWITCH

TERMINALS

P1540

PROBE SYSTEM

BU

N

N

®

Mov

ing

Par

ts.

Do n

ot o

pera

te

unit

with

this

pan

el re

mov

ed.

Ris

k O

f Ele

ctric

al S

hoc

k.

Disc

onn

ect

pow

er b

efore

serv

icin

g u

nit.

CH

AR

GE

Typ

e R

22,

Am

oun

t _

_ O

Z.

De

sig

n P

res

sur

es:

H

igh

_ _

L

ow

_ _

Su

ctio

n P

res

sur

e _

_

P1523

5. With the probe box switch in “LOW” position

check the resistance across the signal cable pins,
see Fig. 9.

6. If readings match values indicated, the probe

system is functioning properly. If not, check the
probe boxes.

FIG. 9 SIGNAL CABLE PINS

P1538

BLU (HIGH) from Probe
Box Cable

GRN (OFF) from Probe
Box Cable

TAN (LOW) from Probe Box
Cable

28791 040501

1

2

AFPO-2 & 3

300

P1539

FIG. 10 PROBE BOX CABLE PINS
