Using the Belkin Wireless Network Utility
Using the Quick Connect Screen
The Utility was designed to offer you two methods of connecting to a
wireless network. The Adapter ships with the Utility configured so you
can use the Configuration view to select a wireless network.
A second option allows you to choose to have the Utility open to the
Quick Connect screen. The Quick Connect screen (pictured below)
is a simplified window that shows you the names of the available
networks only, excluding other information like signal strength, MAC
address, network type, channel, etc.
(a) Available Networks
Displays the available networks and their settings
(b) Network Name (SSID)
This is the name of the wireless network
(c) Advanced Button
Click this button to go to the Advanced configuration window
(d) Connect Button
Select a network from the Available Networks window and click to
connect to the network
(a)
(b)
(d)
(c)
