General Description
General Description
When shipped from the factory, the LCD display is covered with a protective sheet to
prevent damage. Remove this sheet before using the P-touch.
Tape compartment cover
Keyboard
Tape viewer
LCD display
Tape cassette compartment
Tape cutter
Print head
Release lever
Tape exit slot
AC adaptor connector
USB port
Battery compartment
cover
Battery case
