DualRunners – Communication Protocol v1.3 - 19 -
Data Capture
for Workforce
in Motion
2.3.5. Capture messages
Code ID 0xE0-0xE1
Description Get Capture Version
Payload None
Response “Capture Version String” or {0} if not applicable
Remarks Capture Version Strings can be :
"DUAL_1D" the scanner is a DualRunners with a 1D non decoded scan engine + an
RFID external daughter board
"DUAL_2D" the scanner is a DualRunners with a 2D decoded HHP scan engine + an
RFID external daughter board
Code ID 0xE2-0xE3
Description Get Mode
Payload None
Response 1 byte:
{0 = trigger, 1 = smart autoscan, 2 = disabled, 3= autoscan, 4=aiming trigger scan}
Code ID 0xE4-0xE5
Description Set Mode
Payload 1 byte OR
2 bytes if aiming trigger scan mode
{0 = trigger, 1 = smart autoscan, 2 = disabled, 3= autoscan, 4=aiming trigger scan}
{aiming trigger scan mode timeout value in second}
Response 1 byte:
{(Bit 0: Success)}
Code ID 0xE6-0xE7
Description Get Data Format
Payload None
Response 1 byte:
{(Bit 2:Timestamp)
(Bit 1: Capture Prefix)
(Bit 0: Capture Suffix)}
Code ID 0xE8-0xE9
Description Set Data Format
Payload 1 byte:
{(Bit 7 = 0: Timestamp config select, =1: Timestamp config deselect)
(Bit 6 = 0: Capture Prefix config select, =1: Capture Prefix config deselect)
(Bit 5 = 0: Capture Suffix config select, =1: Capture Suffix config deselect)
(Bit 2:Timestamp)
(Bit 1: Capture Prefix)
(Bit 0: Capture Suffix) }
Response 1 byte:
