DualRunners – Communication Protocol v1.3 - 15 -
Data Capture
for Workforce
in Motion
2.3.4. Miscellaneous messages
Code ID 0xC2-0xC3
Description Get/Set DataPrefix
Payload Get : None
Set : 1-33 bytes:
{ DataPrefix length}
“DataPrefix String”
Response Get : 1-33 bytes:
{ DataPrefix length}
“DataPrefix String”
Set : 1 byte:
{Success?}
Remarks Configure value of ‘DataPrefix’
Code ID 0xC4-0xC5
Description Get/Set DataSuffix
Payload Get : None
Set : 1-33 bytes:
{ DataSuffix length}
“DataSuffix String”
Response Get : 1-33 bytes:
{ DataSuffix length}
“DataSuffix String”
Set : 1 byte:
{Success?}
Remarks Configure value of ‘DataSuffix’
Code ID 0xC6-0xC7
Description Get/Set Data Format 2
Payload Get : None
Set : 1 byte:
{(Bit 5 = 0: DataPrefix config select, =1: DataPrefix config deselect)
(Bit 4 = 0: DataSuffix config select, =1: DataSuffix config deselect)
(Bit 1: DataPrefix)
(Bit 0: DataSuffix)
Response Get : 1 byte:
{(Bit 1: DataPrefix)
(Bit 0: DataSuffix)}
Set : 1 byte:
{(Bit 0:Success)}
Remarks Enable, disable the adding of ‘Data Prefix’ and ‘Data Suffix’
