en | Set up FMS
Fire Monitoring System
F.01U.032.785 | A3 | 2007.05
Installation Guide
Bosch Security Systems
Configuration
After installation, perform the following steps to configure your
software:
1.
Double-click the FMS Manager icon on your desktop.
2.
Enter Administrator as the user name and password.
3.
Click the OK button. The FMS Manager opens, allowing
you to configure the system.
4.
Click the button Execute - FMS Configuration Wizard in the
System start/stop tab. The configuration program opens.
5.
Click the Next button. A log-on screen opens.
6.
Enter Administrator as the user name and password.
7.
Click the OK button. The configuration program continues.
8.
Insert the disk supplied.
9.
Step 1/6: Select the dongle.crp file from the disk.
10. Click the Next button.
11. Step 2/6: Note the determined server name.
12. Click the Next button.
13. Step 3/6: Specify a COM port (maximum of four) for each
panel in the drop-down menu.
14. Click the Next button.
15. Step 4/6: Click the
button and select the
corresponding detector check plan .mpp for each
COM port.
16. Click the Next button.
17. Step 5/6: Click the
button and enter the path of the
folder containing the floor plans.
18. Click the Next button.
19. Step 6/6: Create all operators and their roles.
20. Then click the Create button.
21. Click the Close button to complete the configuration.
i
NOTICE!
Click the Help button of the FMS Manager for additional
information on configuration.
