HEAT PUMP HEATING PERFORMANCE
See notes on page 17.
INDOOR
AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES °F
–3 7 17 27 37 47 57 67
EDB CFM
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Capacity
MBtuh†
Total
Pwr
Total Int* Kw† Total Int* Kw† Total Int* Kw† Total Int* Kw† Total Int* Kw† Total Int* Kw† Total Int* Kw† Total Int* Kw†
650AN024-A,C Outdoor Section With FX4ANF030 Indoor Section
65
700 12.0 11.1 1.79 14.3 13.1 1.87 16.6 15.1 1.95 19.0 16.9 2.04 21.9 19.9 2.16 25.0 25.0 2.30 28.5 28.5 2.48 32.6 32.6 2.74
800 12.2 11.2 1.80 14.5 13.3 1.87 16.8 15.3 1.95 19.2 17.1 2.03 22.1 20.1 2.13 25.4 25.4 2.27 28.9 28.9 2.44 33.1 33.1 2.69
900 12.4 11.4 1.82 14.6 13.4 1.88 17.0 15.5 1.95 19.4 17.3 2.03 22.4 20.4 2.13 25.6 25.6 2.25 29.3 29.3 2.43 33.4 33.4 2.67
70
700 11.8 10.8 1.87 14.1 13.0 1.96 16.4 15.0 2.05 18.8 16.7 2.14 21.6 19.6 2.26 24.7 24.7 2.41 28.1 28.1 2.60 32.0 32.0 2.87
800 12.0 11.0 1.88 14.3 13.1 1.96 16.6 15.1 2.04 19.0 16.9 2.13 21.8 19.9 2.24 25.0 25.0 2.38 28.5 28.5 2.56 32.5 32.5 2.81
900 12.1 11.2 1.90 14.4 13.3 1.97 16.8 15.3 2.05 19.2 17.0 2.13 22.1 20.1 2.23 25.3 25.3 2.36 28.8 28.8 2.54 32.9 32.9 2.79
75
700 11.5 10.6 1.96 13.9 12.8 2.05 16.2 14.8 2.15 18.5 16.5 2.25 21.3 19.4 2.38 24.3 24.3 2.53 27.7 27.7 2.73 31.5 31.5 3.00
800 11.7 10.7 1.97 14.1 13.0 2.06 16.4 15.0 2.14 18.8 16.7 2.23 21.5 19.6 2.35 24.6 24.6 2.50 28.1 28.1 2.68 32.0 32.0 2.94
900 11.8 10.9 1.98 14.3 13.1 2.07 16.6 15.1 2.15 19.0 16.8 2.23 21.8 19.8 2.34 24.9 24.9 2.48 28.4 28.4 2.66 32.4 32.4 2.91
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
FX4ANF 030 1.00 1.00 CE3AA 030 0.98 1.01
F(A,B)4AN(F,C) 030 0.98 1.01 036 0.98 1.01
FC4BNF 030 0.98 1.01 CJ5A/CK5A/CK5BA 030 0.98 1.01
FK4CNF 001 0.95 0.95 036 0.99 0.98
002 1.00 0.92 CJ5A/CK5A/CK5BN 036 0.99 0.98
003 1.01 0.94 CJ5A/CK5A/CK5BW 030 0.98 1.01
FV4ANF 002 1.01 0.97 036 0.99 0.98
003 1.00 0.96 CK3BA 030 0.98 1.01
— — — 036 0.99 0.98
650AN030-A,C Outdoor Section With FX4ANF030 Indoor Section
65
825 12.6 11.6 2.07 15.4 14.1 2.12 18.3 16.7 2.16 21.6 19.2 2.22 25.4 23.1 2.29 29.7 29.7 2.39 34.6 34.6 2.69 32.7 32.7 2.55
1050 12.9 11.9 2.11 15.7 14.4 2.14 18.7 17.0 2.17 22.0 19.6 2.21 25.9 23.6 2.27 30.4 30.4 2.35 35.4 35.4 2.63 33.5 33.5 2.49
1250 13.2 12.2 2.15 16.0 14.7 2.17 19.0 17.3 2.19 22.4 19.9 2.23 26.3 23.9 2.28 30.8 30.8 2.36 36.0 36.0 2.64 33.9 33.9 2.49
70
825 12.3 11.3 2.18 15.2 14.0 2.23 18.1 16.5 2.28 21.4 19.0 2.33 25.1 22.8 2.41 29.4 29.4 2.52 34.1 34.1 2.82 32.2 32.2 2.67
1050 12.7 11.7 2.21 15.6 14.3 2.25 18.5 16.9 2.28 21.8 19.4 2.32 25.6 23.3 2.38 30.0 30.0 2.47 34.9 34.9 2.76 33.0 33.0 2.60
1250 13.0 11.9 2.25 15.8 14.5 2.28 18.8 17.1 2.30 22.1 19.6 2.34 26.0 23.6 2.39 30.4 30.4 2.47 35.4 35.4 2.76 33.4 33.4 2.60
75
825 12.0 11.1 2.29 15.0 13.7 2.34 18.0 16.4 2.40 21.1 18.8 2.46 24.8 22.6 2.54 29.0 29.0 2.65 33.7 33.7 2.96 31.7 31.7 2.80
1050 12.4 11.4 2.32 15.3 14.1 2.35 18.3 16.7 2.40 21.6 19.1 2.44 25.3 23.0 2.50 29.6 29.6 2.59 34.4 34.4 2.89 32.5 32.5 2.72
1250 12.7 11.7 2.36 15.6 14.4 2.39 18.6 17.0 2.42 21.9 19.4 2.45 25.7 23.4 2.51 30.0 30.0 2.59 34.9 34.9 2.89 33.0 33.0 2.71
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
FX4ANF 030 1.00 1.00 FV4ANF 002 0.97 0.94
F(A,B)4AN(F,C) 030 0.98 1.02 003 0.95 0.92
036 0.99 1.03 FX4ANF 036 1.00 1.01
FC4BNF 030 0.98 1.02 CE3AA 036 0.97 1.01
036 0.99 1.03 CJ5A/CK5A/CK5BN 036 0.98 0.99
FK4CNF 001 0.95 0.96 CJ5A/CK5A/CK5BW 036 0.98 0.98
002 0.97 0.94 CK3BA 036 0.98 0.98
003 0.95 0.92 — — —
