Projected Image Size
NOTE: Use these charts and
tables to help you determine pro-
jected image sizes.
F
IGURE
29
Projected image size for CD-450m
Table 1:
Image Size, Width and Height for CD-450m-maximum image size
Distance to
Screen (feet)
Diagonal
(feet)
Width
(feet)
Height
(feet)
4.9
3.0
2.4
1.8
8
5.0
4.0
3.0
12
7.6
6.1
4.6
16
10.1
8.1
6.1
20
12.6
10.1
7.6
30
18.9
15.1
11.3
Table 2:
Image Size, Width and Height for CD-450m-maximum image size
(metric)
Distance to
Screen (m)
Diagonal
(m)
Width
(m)
Height
(m)
1.5
.7
.6
04
2.4
1.2
1.0
.7
3.7
1.8
1.4
1.1
4.9
2.3
1.8
1.4
6.1
2.9
2.3
1.7
9.1
4.4
3.5
2.6
