Transport dimensions and weights, Basic machine, Crawler 2x – Liebherr HS 855 HD Litronic User Manual
Page 3: 10 ft, 20 ft, 40 ft, Boom head, Basic machine and boom, Boom transport option, Transport option
HS 855 HD 3
*
)
Including pendant ropes
with HD undercarriage, boom foot (No. 1311.xx), A–frame, 2x 55,200 lbs
winches including wire ropes (295 ft), without basic counterweight
Basic machine
Weight in lbs
129,400
Width
11’6”
Triple grouser track shoes
31.5”
Crawler
2x
Weight in lbs
21,300
Width
36”
Boom section
(No. 1311.xx)
10 ft
Weight in lbs*
1,100
Width
55”
Boom section
(No. 1311.xx)
20 ft
Weightin lbs*
1,800
Width
55”
Boom section
(No. 1311.xx)
40 ft
Weight in lbs*
2,800
Width
55”
Boom head
(No. 1311.xx)
Weight in lbs*
4,350
Width
55”
Transport dimensions and weights
Basic machine and boom
(No. 1311.xx)
Boom transport option
Length
39’10”
Weight in lbs*
11,110
С
С
С
С
С
С
С
С
С
С
С
С
С
С
С
С
С
С
С
С
С
С
С
С
С
С
С
С
С
С
С
С
С
С
С
Transport option
with boom foot (No. 1311.xx), A–frame, 2x 55,200 lbs winches including
wire ropes (295 ft), without basic counterweight and crawlers
Basic machine
Weight in lbs
86,900
Width
11’6”
С
С
С
С
С
