Capacities in 1000 lbs with fixed jib (No. 0806.xx), 71,200 lbs counterweight + 33,100 lbs carbody counterweight. Above lift chart is for reference only.
For actual lift duty and complete chart with all available configurations please refer to lift chart in operator’s cab or manual.
Lift chart - fixed jib
(No. 0806.xx)
Offset 15°
14 HS 855 HD
Main boom 36 ft
Fixed jib length in (ft)
36
66
85
105
Radius (ft)
lbs
lbs
lbs
lbs
16.8
60.4
35
41.8
25.1
40
38.8
23.4
16.2
50
34.9
21.0
13.1
9.5
55
33.6
20.2
12.5
9.2
60
32.2
19.5
11.9
8.9
65
30.4
18.9
11.4
8.7
80
16.3
10.1
8.0
95
14.5
9.0
7.5
110
8.4
7.2
120
7.0
130
6.8
Main boom 105 ft
Fixed jib length in (ft)
36
66
85
105
Radius (ft)
lbs
lbs
lbs
lbs
24
48.4
40
39.3
21.7
50
36.5
20.3
13.2
60
32.0
19.5
12.5
8.9
80
21.2
18.4
11.3
8.2
90
17.8
17.8
10.8
7.9
100
15.0
16.1
10.3
7.7
110
12.8
13.9
9.8
7.5
120
11.0
12.0
9.5
7.3
150
7.9
8.3
6.8
170
6.4
6.6
190
5.1
Main boom 164 ft
Fixed jib length in (ft)
36
66
85
105
Radius (ft)
lbs
lbs
lbs
lbs
30.2
31.5
45
28.4
16.9
55
26.7
16.2
11.6
65
23.9
15.9
11.2
8.0
80
20.2
15.2
10.8
7.7
100
14.0
14.3
9.7
7.4
120
9.9
10.9
9.1
7.1
140
7.1
8.0
8.4
6.8
165
4.5
5.3
5.7
6.1
175
4.5
4.9
5.2
180
4.5
4.8
185
4.4
Main boom 66 ft
Fixed jib length in (ft)
36
66
85
105
Radius (ft)
lbs
lbs
lbs
lbs
19.9
56.1
35
43.1
24.5
45
38.8
21.9
14.0
55
36.0
20.5
12.9
9.2
60
33.1
20.1
12.4
8.9
70
26.9
19.2
11.6
8.6
80
22.4
18.4
10.8
8.2
85
20.5
17.8
10.5
8.0
90
18.9
17.2
10.2
7.9
120
13.0
8.7
7.2
140
8.2
6.9
160
6.6
Main boom 125 ft
Fixed jib length in (ft)
36
66
85
105
Radius (ft)
lbs
lbs
lbs
lbs
26.1
41.8
40
36.6
21.7
50
33.9
19.3
12.9
60
31.8
18.6
12.3
8.7
80
21.0
17.8
11.3
8.1
100
14.8
15.9
10.5
7.7
120
10.8
11.7
9.7
7.3
130
9.3
10.2
9.3
7.1
140
7.9
8.8
8.9
7.0
170
5.7
6.1
6.5
190
4.5
4.9
195
4.5
Main boom 174 ft
Fixed jib length in (ft)
36
56
66
76
Radius (ft)
lbs
lbs
lbs
lbs
31.2
28.8
45
26.1
18.7
17.2
50
25.1
18.3
15.7
14.5
60
23.3
17.7
15.2
13.1
80
19.6
16.3
14.4
12.6
100
13.7
14.5
13.3
10.6
120
9.7
10.4
10.6
9.5
140
6.8
7.4
7.7
8.0
160
4.7
5.3
5.5
5.8
165
4.8
5.1
5.3
170
4.6
4.8
175
4.4
Main boom 85 ft
Fixed jib length in (ft)
36
66
85
105
Radius (ft)
lbs
lbs
lbs
lbs
22
52.7
40
40.7
22.8
45
38.7
21.7
15.1
55
35.9
20.4
12.9
9.1
60
32.6
19.9
12.5
8.9
70
26.3
19.3
11.8
8.6
80
21.8
18.6
11.2
8.2
90
18.3
18.0
10.6
7.9
105
14.4
15.5
9.8
7.5
135
10.2
8.6
7.0
155
8.2
6.7
175
6.5
Main boom 144 ft
Fixed jib length in (ft)
36
66
85
105
Radius (ft)
lbs
lbs
lbs
lbs
28.1
36.6
45
31.8
18.3
55
29.3
17.6
12.2
60
28.1
17.4
11.9
9.0
80
20.5
16.7
11.1
8.0
100
14.3
15.2
10.3
7.6
120
10.2
11.2
9.6
7.2
140
7.4
8.3
8.7
6.9
160
5.2
6.1
6.5
6.5
175
4.7
5.2
5.5
180
4.8
5.1
185
4.7
Main boom 184 ft
Fixed jib length in (ft)
36
46
56
Radius (ft)
lbs
lbs
lbs
32.2
25.4
40
24.4
21.2
45
23.6
20.7
17.7
60
21.6
19.1
16.7
80
17.8
16.6
15.3
100
13.4
13.8
13.8
120
9.4
9.7
10.1
130
7.8
8.2
8.5
140
6.5
6.8
7.2
150
5.4
5.7
6.0
160
4.4
4.7
5.0
165
4.5
