HS 855 HD 11
Lift chart for main boom
(No. 1311.xx)
58,000 lbs counterweight
Capacities in 1000 lbs for boom lengths (36 ft – 203 ft) – with 55,200 lbs winches
58,000 lbs counterweight
Boom length in (ft)
Radius
36
46
66
75
85
95
105
115
125
135
144
154
164
174
184
194
203
Radius
(ft)
lbs
lbs
lbs
lbs
lbs
lbs
lbs
lbs
lbs
lbs
lbs
lbs
lbs
lbs
lbs
lbs
lbs
(ft)
10.5
200.0
10.5
15
200.0 200.0 193.8 188.3 178.1 157.7 137.6 115.1
99.4
15
20
120.4 120.9 121.2 121.2 121.2 119.2 116.7 114.5
99.4
80.2
67.1
62.1
54.8
48.3
40.4
33.9
20
25
85.4
85.8
86.0
86.0
85.9
85.8
85.7
85.9
84.4
76.7
66.2
62.1
54.8
48.3
40.4
33.9
29.4
25
30
65.6
66.0
66.2
66.1
66.0
65.9
65.7
65.9
65.8
65.6
62.6
58.2
51.9
46.5
40.3
33.9
29.4
30
35
52.8
53.2
53.4
53.3
53.2
53.1
52.9
53.1
52.9
52.7
52.6
52.6
48.8
42.3
37.7
31.9
28.1
35
40
44.5
44.7
44.6
44.5
44.4
44.2
44.4
44.2
44.0
43.8
43.9
43.6
39.7
35.5
30.1
26.5
40
45
37.9
38.1
38.0
37.9
37.7
37.5
37.8
37.6
37.4
37.2
37.2
37.0
36.8
33.6
28.4
24.7
45
50
33.0
33.0
32.8
32.7
32.4
32.7
32.5
32.3
32.1
32.1
31.9
31.7
31.5
27.1
23.4
50
55
29.0
28.9
28.8
28.6
28.4
28.7
28.4
28.2
28.0
28.1
27.9
27.6
27.4
26.2
22.5
55
60
25.7
25.7
25.5
25.3
25.1
25.4
25.2
25.0
24.7
24.8
24.6
24.3
24.1
24.1
21.8
60
65
22.9
22.9
22.8
22.6
22.4
22.7
22.5
22.2
22.0
22.1
21.8
21.6
21.4
21.4
21.1
65
70
20.6
20.5
20.3
20.1
20.4
20.2
20.0
19.7
19.8
19.6
19.3
19.1
19.1
18.8
70
75
18.6
18.5
18.4
18.2
18.4
18.2
18.0
17.7
17.8
17.6
17.4
17.1
17.1
16.9
75
80
16.8
16.7
16.5
16.8
16.5
16.3
16.1
16.1
15.9
15.7
15.4
15.4
15.2
80
85
15.3
15.2
15.0
15.3
15.1
14.8
14.6
14.7
14.4
14.2
13.9
13.9
13.7
85
90
13.9
13.7
14.0
13.8
13.5
13.3
13.4
13.1
12.9
12.6
12.6
12.4
90
95
12.7
12.5
12.8
12.6
12.4
12.1
12.2
12.0
11.8
11.5
11.5
11.2
95
100
11.4
11.8
11.6
11.4
11.1
11.2
11.0
10.7
10.5
10.5
10.2
100
105
10.8
10.6
10.4
10.2
10.3
10.0
9.8
9.5
9.5
9.3
105
110
10.0
9.8
9.6
9.3
9.4
9.2
9.0
8.7
8.7
8.5
110
115
9.0
8.8
8.6
8.7
8.4
8.2
7.9
7.9
7.7
115
120
8.3
8.1
7.9
8.0
7.7
7.5
7.2
7.3
7.0
120
125
7.5
7.2
7.3
7.1
6.9
6.6
6.6
6.4
125
130
6.8
6.6
6.8
6.5
6.3
6.0
6.0
5.8
130
135
6.1
6.2
6.0
5.7
5.5
5.5
5.2
135
140
5.5
5.7
5.5
5.2
5.0
5.0
4.7
140
145
5.2
5.0
4.8
4.5
4.5
4.3
145
150
4.8
4.6
4.3
4.1
4.1
3.8
150
155
4.1
3.9
3.7
3.7
3.4
155
160
3.7
3.5
3.3
3.3
3.1
160
165
3.2
2.9
3.0
2.7
165
170
2.8
2.6
2.6
2.4
170
175
2.2
2.3
175
Above lift chart is for reference only. For actual lift duty please refer to lift chart in operator’s cab or manual.
