T R O U B L E S H O O T I N G A N D R O U T I N E M A I N T E N A N C E 13 - 6
Replacing the Print Cartridge
WARNING
Be careful not to cut yourself on the sharp edges of the metal part shown in the
illustration.
1
Push the OPEN button to open the top cover.
2
Take out the used print cartridge.
3
Remove the stopper from the printing cartridge.
4
Turn the black spool on the right clockwise to tighten the ribbon.
Sharp Edge
OPEN button
Stopper
Black Spool
Blue shaft
White shaft
Recessed arrow
