Table 8 Con’t—Dry Coil Air Delivery* -- Horizontal and Downflow Discharge --
Unit 574D024--060 (Deduct 10% for 208 Volts)
Unit
Heating Rise
Range o F (°C)
Motor
Speed
External Static Pressure (in. wc)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9
574D048090
25 --- 55
(14 --- 31)
Low
Watts 627 617 607 584 567 548 528 503 480
CFM 1550 1530 1493 1461 1414 1361 1320 1250 1177
Heating Rise o F
°C
44
24
44
24
45
25
46
26
48
27
50
28
51
28
54
30
NA
Medium 1
Watts 771 755 734 711 690 665 639 607 572
CFM 1798 1771 1734 1687 1645 1595 1530 1449 1355
Heating Rise o F
°C
38
21
38
21
39
22
40
22
41
23
42
24
44
25
47
26
50
28
High
Watts 969 941 908 887 858 827 804 767 748
CFM 2124 2071 2000 1944 1876 1811 1735 1647 1555
Heating Rise o F
°C
32
18
33
18
34
19
35
19
36
20
37
21
39
22
41
23
43
24
574D048115
35 --- 65
(19 --- 36)
Low
Watts 627 617 607 584 567 548 528 503 480
CFM 1550 1530 1493 1461 1414 1361 1320 1250 1177
Heating Rise o F
°C
56
31
56
31
58
32
59
33
61
34
63
35
65
36
NA NA
Medium 1
Watts 771 755 734 711 690 665 639 607 572
CFM 1798 1771 1734 1687 1645 1595 1530 1449 1355
Heating Rise o F
°C
48
27
49
27
50
28
51
28
52
29
54
30
56
31
60
33
64
35
High
Watts 969 941 908 887 858 827 804 767 748
CFM 2124 2071 2000 1944 1876 1811 1735 1647 1555
Heating Rise o F
°C
41
23
42
23
43
24
44
25
46
26
48
26
50
28
52
29
55
31
574D048130
40 --- 70
(22 --- 39)
Low
Watts 627 617 607 584 567 548 528 503 480
CFM 1550 1530 1493 1461 1414 1361 1320 1250 1177
Heating Rise o F
°C
63
35
64
35
65
36
67
37
69
38
NA NA NA NA
Medium 1
Watts 771 755 734 711 690 665 639 607 572
CFM 1798 1771 1734 1687 1645 1595 1530 1449 1355
Heating Rise o F
°C
54
30
55
31
56
31
58
32
59
33
61
34
64
35
67
37
NA
High
Watts 969 941 908 887 858 827 804 767 748
CFM 2124 2071 2000 1944 1876 1811 1735 1647 1555
Heating Rise o F
°C
46
26
47
26
49
27
50
28
52
29
54
30
56
31
59
33
63
35
574D060090
25 --- 55
(14 --- 31)
Low 1
Watts 786 769 754 736 722 705 684 658 616
CFM 2027 1960 1901 1821 1759 1693 1616 1513 1354
Heating Rise o F
°C
33
19
34
19
36
20
37
21
38
21
40
22
42
23
45
25
50
28
Medium
Watts 873 849 833 815 798 782 763 748 704
CFM 2095 2026 1962 1887 1817 1748 1679 1583 1439
Heating Rise o F
°C
32
18
33
19
34
19
36
20
37
21
39
21
40
22
43
24
47
26
High
Watts 1012 993 981 963 948 927 904 886 846
CFM 2184 2109 2036 1963 1886 1812 1729 1647 1496
Heating Rise o F
°C
31
17
32
18
33
18
34
19
36
20
37
21
39
22
41
23
45
25
574D060115
35 --- 65
(19 --- 36)
Low 1
Watts 786 769 754 736 722 705 684 658 616
CFM 2027 1960 1901 1821 1759 1693 1616 1513 1354
Heating Rise o F
°C
43
24
44
24
45
25
47
26
49
27
51
28
53
30
57
32
64
35
Medium
Watts 873 849 833 815 798 782 763 748 704
CFM 2095 2026 1962 1887 1817 1748 1679 1583 1439
Heating Rise o F
°C
41
23
43
24
44
24
46
25
47
26
49
27
51
29
54
30
60
33
High
Watts 1012 993 981 963 948 927 904 886 846
CFM 2184 2109 2036 1963 1886 1812 1729 1647 1496
Heating Rise o F
°C
39
22
41
23
42
24
44
24
46
25
48
26
50
28
52
29
58
32
574D060130
40 --- 70
(22 --- 39)
Low 1
Watts 786 769 754 736 722 705 684 658 616
CFM 2027 1960 1901 1821 1759 1693 1616 1513 1354
Heating Rise o F
°C
48
27
50
28
51
28
54
30
55
31
58
32
60
34
64
36
NA
Medium
Watts 873 849 833 815 798 782 763 748 704
CFM 2095 2026 1962 1887 1817 1748 1679 1583 1439
Heating Rise o F
°C
47
26
48
27
50
28
52
29
54
30
56
31
58
32
62
34
68
38
High
Watts 1012 993 981 963 948 927 904 886 846
CFM 2184 2109 2036 1963 1886 1812 1729 1647 1496
Heating Rise o F
°C
45
25
46
26
48
27
50
28
52
29
54
30
56
31
59
33
65
36
* Air delivery values are without air filter and are for dry coil (See Table 15 -- 574D Wet Coil Pressure Drop table).
1 Factory--shipped heating/cooling speed
NA = Not allowed for heating speed
Note: Deduct field--supplied air filter pressure drop and wet coil pressure drop to obtain external static pressure available for ducting.
