26
NOTE: Menu selection is case sensitive. It is recommended that your
keyboard be in the CAPS LOCK position. In the configuration mode,
some characters are displayed with a HEX notation since all
combinations from 00 Hex TO 7F Hex may be selected.
By responding to the Enter Request: message at the end of the main
configuration menu (see
Section 6.1 ) with " 1 " (Status), you may view
the status of all ports and the current operation protocol. The
multiport will respond as follows:
| Port • Baud •Word •Stop •Parity •Xon/ |
| • Rate •Size •Bits • •Xoff |
|
| 1 • 9600 • 8 • 1 • None • Off |
| 2 • 9600 • 8 • 1 • None • Off |
| 3 • 9600 • 8 • 1 • None • Off |
| 4 • 9600 • 8 • 1 • None • Off |
| 5 • 9600 • 8 • 1 • None • Off |
| 6 • 9600 • 8 • 1 • None • Off |
| 7 • 9600 • 8 • 1 • None • Off |
| 8 • 9600 • 8 • 1 • None • Off |
| 9 • 9600 • 8 • 1 • None • Off |
Press Any Key to Continue
OPERATION PROTOCOL
••••••••••••••••••••••••••••••••••••••••••••••
• Mode • Control Char. • RCV • RCV • RCV •
• of •••••••••••••••••• Port • Term •Block •
• Oper.• XMIT • RCV • I.D. • Chr. •Length•
••••••••••••••••••••••••••••••••••••••••••••••
• 1 • 14H n • 14H n • N/A • N/A • N/A •
• 2 • 14H n • N/A • n • 0DH • N/A •
• 3 • 14H n • 14H S • n • 0DH • N/A •
• 4 • 14H n • 14H Sn • n • 0DH • N/A •
• 5 • 14H n • 14H Sn • n • 0DH • N/A •
• 6 • 14H n • N/A •14H n • N/A • 032 •
••••••••••••••••••••••••••••••••••••••••••••••
H = Hexadecimal
S = 53H
n = ASCII Port Number (1 to 9 or 31H to 39H)
N/A = Not Applicable
Current Terminate Character is.............0DH
Current Block Length is....................032
Current Control Character is...............14H
Current Mode of Operation is.................1
Press Any Key To Continue
