17
8.
Place the two halves of the strain-relief assembly on either side of the
twisted-pair wire and press together very lightly. Slide the assembly so that
it is about two inches (5.1 cm) from the terminal posts and press together
firmly.
9.
Insert the strain-relief assembly with the wire going through it into the
slot in the bottom half of the modem case and set it into the recess in the
case.
+RCV
-G-XMT+
+RCV
-G-XMT+
+RCV
-G-XMT+
CHAPTER 4: Installation
