11

CHAPTER 3: Configuration

3.2.1 DIP-S

WITCH

S

ETTINGS

The factory-default settings for the switches are presented below. Read the

information following the table for an explanation of the switch’s function.

Switch S1 Summary Table

Position

Function

Factory Default

S1-1*

“Transmit Off” Impedance

Off

High Z

S1-2*

“Transmit Off” Impedance

Off

S1-3

RTS/CTS Delay

On

8 msec.

S1-4

Echo Mode

Off

Echo Off

S1-5

Carrier Control

On

Controlled by RTS

S1-6

Receive Impedance

On

120 ohm

S1-7*

2 wire/4 wire

On

2-wire

S1-8*

2 wire/4 wire

On

*Note: Switches S1-1 and S1-2 should be switched simultaneously.

Switches S1-7 and S1-8 should also be switched simultaneously.

S1-1 and S1-2: “Transmit Off” Impedance

Switches S1-1 and S1-2 are set together to determine whether the receiving

device “sees” the impedance of the Converter’s transmitter as being “high”

or “intermediate” when the transmitter is turned off. The “intermediate”

setting is useful in half-duplex environments where the receiving device

does not respond well to the “high” setting.

S1-1

S1-2

Setting

On

On

Intermediate Impedance

Off

Off

High Impedance

S1-3: RTS/CTS Delay

The setting for switch S1-3 determines the amount of delay between the

time the Converter “sees” RTS and when it sends CTS. Note: RTS/CTS

Delay setting should be based upon transmission timing.

S1-3

Setting

On

8 msec.

Off

No delay
