CHAPTER 3: Configuration
3.2.2 C
ONFIGURATION
S
WITCH
A
PPLICATIONS
The table below shows you how to set the Converter’s switch to fit several
common applications.
Do not change switch settings until you have carefully read
this manual.
If you have any questions about the proper settings for your
application, call your supplier for technical support.
Typical Switch Applications
Switch Settings
Point-to-Point
Multipoint
4W
4W HDX
2W
4W
2W
“Xmt Off” Imp. (S1-1)
Off
Off
Off
Off
Off
“Xmt Off” Imp. (S1-2)
Off
Off
Off
Off
Off
RTS/CTS Delay (S1-3)
On
On
On
Off
On
Echo (S1-4)
Off
Off
Off
Off
Off
Carrier Control (S1-5)
Off
On
On
Master—Off
On
Slaves—On
Rcv. Impedance (S1-6)
On
On
On
Master—On
Slaves—Off
Last Slave—On
2-wire/4-wire (S1-7)
Off
Off
On
Off
On
2-wire/4-wire (S1-8)
Off
Off
On
Off
On
3.2.3 W
HEN
Y
OU
’
RE
F
INISHED
C
ONFIGURING
Once you’ve finished setting the Converter’s configuration switches,
don’t
snap the case halves back together yet. If you are connecting the RS-485
interface using the internal terminal blocks, go to
Section 4.1.2
and
continue the installation procedure. If you are connecting the RS-485
interface using DB25, go ahead and snap the case halves back together
now. (Don’t force a fit—make sure all the pieces are properly set before
snapping the case halves shut.)
