CONDENSER ONLY RATINGS* Continued
* ARI listing applies only to systems shown in Combination Ratings table.
KW — Outdoor Unit Kilowatts Only
SDT — Saturated Temperature Leaving Compressor (°F)
SST — Saturated Temperature Entering Compressor (°F)
TCG — Gross Cooling Capacity (1000 Btuh).
SST
°F
CONDENSER ENTERING AIR TEMPERATURES °F
55
65
75
85
95
105
115
125
550A042-F
30
TCG
SDT
KW
41.4
72.3
1.85
39.2
82.0
2.10
37.0
91.8
2.39
34.8
102.0
2.72
32.5
111.0
3.07
30.2
121.0
3.46
27.8
130.0
3.89
25.3
140.0
4.36
35
TCG
SDT
KW
45.4
73.7
1.86
43.0
83.4
2.12
40.6
93.1
2.41
38.2
103.0
2.74
35.7
112.0
3.09
33.2
122.0
3.49
30.6
131.0
3.92
27.8
141.0
4.39
40
TCG
SDT
KW
49.6
75.2
1.88
47.0
84.8
2.14
44.5
94.4
2.43
41.8
104.0
2.76
39.1
114.0
3.12
36.4
123.0
3.51
33.5
133.0
3.94
30.5
142.0
4.41
45
TCG
SDT
KW
54.0
76.7
1.89
51.3
86.3
2.16
48.5
95.9
2.45
45.7
106.0
2.78
42.7
115.0
3.14
39.8
125.0
3.54
36.7
134.0
3.97
33.3
143.0
4.44
50
TCG
SDT
KW
58.8
78.4
1.92
55.8
87.9
2.18
52.8
97.4
2.47
49.7
107.0
2.80
46.6
117.0
3.17
43.3
126.0
3.57
39.9
135.0
4.00
36.3
144.0
4.47
55
TCG
SDT
KW
63.8
80.2
1.94
60.6
89.6
2.20
57.4
99.1
2.50
54.0
109.0
2.83
50.6
118.0
3.20
47.1
127.0
3.60
43.4
137.0
4.03
39.5
145.0
4.50
550A048-F
30
TCG
SDT
KW
45.8
72.0
2.11
43.3
82.0
2.40
40.9
92.0
2.73
38.5
102.0
3.09
36.0
112.0
3.52
33.6
122.0
3.98
31.0
132.0
4.51
28.4
142.0
5.09
35
TCG
SDT
KW
50.6
72.0
2.10
47.9
82.0
2.39
45.2
92.0
2.71
42.6
102.0
3.08
39.9
112.0
3.49
37.2
122.0
3.96
34.4
132.0
4.48
31.5
142.0
5.06
40
TCG
SDT
KW
55.7
72.3
2.10
52.8
82.1
2.38
49.9
92.0
2.70
47.0
102.0
3.06
44.1
112.0
3.47
41.1
122.0
3.93
38.1
132.0
4.45
34.9
142.0
5.02
45
TCG
SDT
KW
60.9
73.6
2.13
57.8
83.2
2.40
54.7
92.7
2.71
51.7
102.0
3.06
48.6
112.0
3.46
45.4
122.0
3.91
42.1
132.0
4.42
38.5
142.0
4.99
50
TCG
SDT
KW
66.3
75.1
2.17
63.0
84.6
2.44
59.7
94.1
2.75
56.4
104.0
3.09
53.1
113.0
3.48
49.8
123.0
3.92
46.2
132.0
4.41
42.5
142.0
4.96
55
TCG
SDT
KW
72.1
76.7
2.21
68.5
86.1
2.48
65.0
95.6
2.79
61.4
105.0
3.14
57.8
114.0
3.52
54.2
124.0
3.95
50.5
133.0
4.43
46.5
143.0
4.96
550A060-H
30
TCG
57.7
54.6
51.6
48.5
45.4
42.1
38.6
34.6
SDT
75.9
85.1
94.3
103.4
112.5
121.6
130.6
139.4
KW
8.82
9.97
11.22
12.59
14.12
15.83
17.63
19.46
35
TCG
63.5
60.1
56.8
53.3
49.9
46.3
42.4
38.1
SDT
77.7
86.8
95.9
104.9
114.0
122.9
131.8
140.5
KW
8.98
10.12
11.38
12.76
14.28
15.98
17.79
19.72
40
TCG
69.6
65.9
62.2
58.4
54.6
50.6
46.3
41.6
SDT
79.6
88.5
97.5
106.5
115.4
124.3
133.0
141.6
KW
9.16
10.29
11.56
12.94
14.44
16.15
17.95
19.9
45
TCG
76.1
72.0
67.9
63.8
59.5
55.0
50.3
45.10
SDT
81.6
90.5
99.4
108.2
117.0
125.7
134.3
142.7
KW
9.36
10.48
11.76
13.13
14.63
16.32
18.11
20.05
50
TCG
82.8
78.4
73.9
69.3
64.5
59.6
54.3
48.6
SDT
83.7
92.5
101.2
110.0
118.6
127.2
135.6
143.8
KW
9.57
10.68
11.97
13.36
14.84
16.5
18.28
20.19
55
TCG
89.8
85.0
80.0
75.0
69.7
64.3
58.5
52.3
SDT
85.9
94.5
103.2
111.8
120.3
128.7
136.9
144.9
KW
9.80
10.9
12.19
13.58
15.07
16.71
18.45
20.34
