Detailed cooling capacities* continued – Bryant 550A User Manual
Page 35
—35—
DETAILED COOLING CAPACITIES* Continued
See notes on page 38.
EVAP
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75
85
95
105
115
125
CFM
EWB
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Total Sens‡
Total Sens‡
Total Sens‡
Total Sens‡
Total Sens‡
Total Sens‡
550A042-F Outdoor Section With CD5AA048 Indoor Section Continued
1225
72
46.7
22.7
2.49
45.2
22.3
2.77
43.3
21.6
3.09
41.2
20.9
3.44
38.8
20.1
3.83
36.0
19.2
4.26
67
44.0
29.5
2.47
42.3
28.9
2.75
39.8
27.8
3.05
37.7
27.1
3.40
35.4
26.3
3.79
31.4
24.7
4.18
63†† 40.5
28.7
2.44
37.8
27.5
2.70
35.0
26.3
3.00
32.0
25.0
3.32
30.2
24.3
3.70
27.8
23.3
4.11
62
39.3
35.4
2.43
36.7
34.1
2.69
33.9
32.7
2.98
31.1
30.9
3.31
29.5
29.5
3.69
27.9
27.9
4.11
57
36.4
36.4
2.40
34.3
34.3
2.67
32.1
32.1
2.96
30.8
30.8
3.30
29.4
29.4
3.69
27.7
27.7
4.11
1400
72
47.1
23.3
2.55
45.8
23.0
2.83
43.9
22.5
3.15
41.8
21.8
3.51
39.3
21.1
3.90
36.5
20.2
4.33
67
44.3
30.5
2.52
42.7
30.2
2.81
40.5
29.4
3.12
38.4
28.8
3.47
35.9
27.9
3.85
31.7
26.4
4.25
63†† 42.1
30.7
2.51
39.3
29.5
2.78
36.4
28.3
3.07
33.6
27.1
3.40
31.8
26.3
3.79
27.9
24.7
4.18
62
40.5
37.9
2.50
37.8
36.5
2.76
35.0
34.8
3.06
32.7
32.7
3.39
31.2
31.2
3.78
29.5
29.5
4.21
57
38.1
38.1
2.48
36.2
36.2
2.74
35.0
35.0
3.05
33.6
33.6
3.40
32.2
32.2
3.79
29.3
29.3
4.20
1575
72
47.5
23.9
2.61
46.2
23.7
2.90
44.4
23.2
3.22
41.8
22.4
3.56
39.5
21.8
3.95
36.8
21.1
4.40
67
44.9
31.9
2.58
43.0
31.5
2.86
41.1
31.1
3.18
38.8
30.3
3.53
36.3
29.6
3.92
32.0
28.0
4.32
63†† 42.5
32.0
2.57
40.5
31.4
2.85
37.6
30.1
3.15
35.0
29.1
3.48
33.1
28.3
3.87
27.9
26.0
4.24
62
41.6
40.2
2.57
38.9
38.5
2.83
36.5
36.5
3.13
35.4
35.4
3.49
32.7
32.7
3.86
30.7
30.7
4.29
57
40.7
40.7
2.56
39.0
39.0
2.83
37.6
37.6
3.15
35.8
35.8
3.49
33.5
33.5
3.87
30.7
30.7
4.29
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section
Size
Cooling
Indoor
Section
Size
Cooling
Capacity
Power
Capacity
Power
CE3AA
042
1.01
0.98
CK5PT
042
1.00
0.97
048
1.01
0.98
048
1.00
0.95
COILS + 355MAV060100 VARIABLE SPEED FURNACE
COILS + 355MAV060120 VARIABLE SPEED FURNACE
CC5A/CD5AA
042
1.00
0.98
CC5A/CD5AA
042
1.00
0.98
CC5A/CD5AC
048
0.99
0.96
CC5A/CD5AW
048
1.00
0.96
CD5AA
048
1.00
0.96
CE3AA
042
1.01
0.98
CE3AA
042
1.01
0.98
048
1.01
0.98
048
1.01
0.98
CK3BA
042
1.00
0.97
CK3BA
042
1.00
0.97
048
1.00
0.95
048
1.00
0.95
CK5A/CK5BA
042
1.00
0.97
CK5A/CK5BA
042
1.00
0.97
CK5A/CK5BT
042
1.00
0.97
048
1.00
0.95
CK5A/CK5BW
048
1.00
0.95
CK5A/CK5BT
042
1.00
0.97
CK5PA
042
1.00
0.97
048
1.00
0.95
CK5PT
042
1.00
0.97
CK5PA
042
1.00
0.97
CK5PW
048
1.00
0.95
048
1.00
0.95
—
—
—
