CONDENSER ONLY RATINGS*
See notes on page 40.
SST
°F
CONDENSER ENTERING AIR TEMPERATURES °F
55 65 75 85 95 105 115 125
550A024-G
30
TCG 20.9 19.4 17.9 16.2 14.4 12.4 10.2 7.8
SDT 69.8 79.1 88.3 97.6 106.7 115.7 124.7 133.6
KW 0.92 1.07 1.24 1.41 1.60 1.78 1.97 2.16
35
TCG 24.2 21.7 20.1 18.4 16.6 14.6 12.4 10.0
SDT 71.3 80.6 89.8 99.1 108.2 117.3 126.2 135.1
KW 0.93 1.10 1.26 1.45 1.64 1.84 2.04 2.25
40
TCG 28.7 25.0 22.5 20.8 19.0 16.9 14.7 12.3
SDT 72.6 82.0 91.4 100.6 109.8 118.9 127.9 136.7
KW 0.94 1.11 1.30 1.48 1.68 1.89 2.11 2.33
45
TCG 37.2 29.3 25.9 23.4 21.4 19.4 17.2 14.8
SDT 73.5 83.4 92.7 101.9 111.3 120.4 129.5 138.3
KW 0.94 1.12 1.31 1.52 1.73 1.95 2.18 2.41
50
TCG 44.0 35.9 30.2 27.0 24.3 22.1 19.9 17.5
SDT 74.4 84.6 94.0 103.2 112.4 121.6 130.6 139.5
KW 0.94 1.13 1.32 1.53 1.76 2.00 2.24 2.48
55
TCG 51.6 45.6 35.8 31.2 27.9 25.3 22.8 20.4
SDT 75.2 85.1 95.3 104.6 113.7 122.8 131.8 140.7
KW 0.90 1.12 1.33 1.55 1.78 2.03 2.30 2.58
550A030-F
30
TCG
SDT
KW
29.9
75.3
1.42 28.2
85.3
1.61 26.6
95.3
1.82 25.0
105.0
2.07
23.4
115.0
2.34
21.8
125.0
2.64
20.2
135.0
2.98
18.4
145.0
3.36
35
TCG
SDT
KW
32.9
75.9
1.42 31.1
85.8
1.61 29.4
95.7
1.82 27.7
106.0
2.06
25.9
116.0
2.33
24.1
126.0
2.63
22.3
135.0
2.96
20.4
146.0
3.34
40
TCG
SDT
KW
36.1
76.7
1.42 34.2
86.5
1.61 32.3
96.3
1.82 30.5
106.0
2.06
28.6
116.0
2.32
26.6
126.0
2.62
24.6
136.0
2.96
22.5
146.0
3.33
45
TCG
SDT
KW
39.5
77.8
1.43 37.5
87.5
1.61 35.4
97.2
1.82 33.4
107.0
2.06
31.3
117.0
2.33
29.2
127.0
2.62
27.1
137.0
2.96
24.7
147.0
3.33
50
TCG
SDT
KW
43.1
79.2
1.44 40.9
88.8
1.63 38.7
98.4
1.83 36.5
108.0
2.07
34.3
118.0
2.33
32.0
128.0
2.63
29.6
138.0
2.96
27.1
147.0
3.33
55
TCG
SDT
KW
46.9
80.8
1.46 44.5
90.2
1.64 42.2
99.8
1.85 39.8
109.0
2.08
37.4
119.0
2.35
34.9
129.0
2.64
32.3
139.0
2.98
29.6
148.0
3.34
550A036-F, G
30
TCG
SDT
KW
36.3
72.2
1.67 34.4
81.8
1.90 32.4
91.3
2.16 30.4
101.0
2.44
28.2
110.0
2.74
26.0
120.0
3.06
23.7
129.0
3.39
21.1
139.0
3.73
35
TCG
SDT
KW
39.8
73.5
1.68 37.8
83.1
1.91 35.6
92.7
2.17 33.5
102.0
2.45
31.2
112.0
2.75
28.8
121.0
3.08
26.3
130.0
3.43
23.6
140.0
3.78
40
TCG
SDT
KW
43.5
75.0
1.68 41.3
84.5
1.91 39.0
94.0
2.17 36.7
104.0
2.46
34.3
113.0
2.77
31.8
122.0
3.10
29.1
132.0
3.46
26.2
141.0
3.83
45
TCG
SDT
KW
47.4
76.6
1.68 45.1
86.0
1.92 42.7
95.4
2.18 40.1
105.0
2.47
37.6
114.0
2.79
34.8
124.0
3.13
32.0
133.0
3.49
28.9
142.0
3.87
50
TCG
SDT
KW
51.5
78.3
1.69 49.1
87.6
1.93 46.5
97.0
2.19 43.8
106.0
2.48
41.0
116.0
2.80
38.1
125.0
3.15
35.0
134.0
3.52
31.7
143.0
3.91
55
TCG
SDT
KW
55.9
80.1
1.70 53.2
89.3
1.93 50.5
98.6
2.20 47.6
108.0
2.50
44.6
117.0
2.82
41.5
126.0
3.17
38.2
135.0
3.54
34.6
144.0
3.94
