Bryant 550A - Manual (Page 33)

—33—
DETAILED COOLING CAPACITIES* Continued
See notes on page 38.
EVAP
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW** Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
550A042-F Outdoor Section With CD5AA048 Indoor Section
1225
72 46.7 22.7 2.49 45.2 22.3 2.77 43.3 21.6 3.09 41.2 20.9 3.44 38.8 20.1 3.83 36.0 19.2 4.26
67 44.0 29.5 2.47 42.3 28.9 2.75 39.8 27.8 3.05 37.7 27.1 3.40 35.4 26.3 3.79 31.4 24.7 4.18
63†† 40.5 28.7 2.44 37.8 27.5 2.70 35.0 26.3 3.00 32.0 25.0 3.32 30.2 24.3 3.70 27.8 23.3 4.11
62 39.3 35.4 2.43 36.7 34.1 2.69 33.9 32.7 2.98 31.1 30.9 3.31 29.5 29.5 3.69 27.9 27.9 4.11
57 36.4 36.4 2.40 34.3 34.3 2.67 32.1 32.1 2.96 30.8 30.8 3.30 29.4 29.4 3.69 27.7 27.7 4.11
1400
72 47.1 23.3 2.55 45.8 23.0 2.83 43.9 22.5 3.15 41.8 21.8 3.51 39.3 21.1 3.90 36.5 20.2 4.33
67 44.3 30.5 2.52 42.7 30.2 2.81 40.5 29.4 3.12 38.4 28.8 3.47 35.9 27.9 3.85 31.7 26.4 4.25
63†† 42.1 30.7 2.51 39.3 29.5 2.78 36.4 28.3 3.07 33.6 27.1 3.40 31.8 26.3 3.79 27.9 24.7 4.18
62 40.5 37.9 2.50 37.8 36.5 2.76 35.0 34.8 3.06 32.7 32.7 3.39 31.2 31.2 3.78 29.5 29.5 4.21
57 38.1 38.1 2.48 36.2 36.2 2.74 35.0 35.0 3.05 33.6 33.6 3.40 32.2 32.2 3.79 29.3 29.3 4.20
1575
72 47.5 23.9 2.61 46.2 23.7 2.90 44.4 23.2 3.22 41.8 22.4 3.56 39.5 21.8 3.95 36.8 21.1 4.40
67 44.9 31.9 2.58 43.0 31.5 2.86 41.1 31.1 3.18 38.8 30.3 3.53 36.3 29.6 3.92 32.0 28.0 4.32
63†† 42.5 32.0 2.57 40.5 31.4 2.85 37.6 30.1 3.15 35.0 29.1 3.48 33.1 28.3 3.87 27.9 26.0 4.24
62 41.6 40.2 2.57 38.9 38.5 2.83 36.5 36.5 3.13 35.4 35.4 3.49 32.7 32.7 3.86 30.7 30.7 4.29
57 40.7 40.7 2.56 39.0 39.0 2.83 37.6 37.6 3.15 35.8 35.8 3.49 33.5 33.5 3.87 30.7 30.7 4.29
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 042 1.00 1.01 CD5AA 048 1.00 0.94
CC5A/CD5AC 048 0.99 1.01 CE3AA 042 1.00 0.95
CC5A/CD5AW 048 1.00 1.00 048 1.01 0.95
CD5AA 048 1.00 1.00 CK3BA 042 1.00 0.95
CE3AA 042 1.01 1.01 048 1.00 0.94
048 1.01 1.00 CK5A/CK5BA 042 0.99 0.93
CF5AA 048 1.00 1.00 048 1.00 0.94
CK3BA 042 1.00 1.00 CK5A/CK5BE 042 1.00 0.94
048 1.00 1.00 CK5A/CK5BT 042 1.00 0.95
CK5A/CK5BA 042 1.00 1.00 048 1.00 0.94
048 1.00 1.00 CK5PA 042 1.00 0.95
CK5A/CK5BE 042 0.98 0.97 048 1.00 0.94
CK5A/CK5BT 042 1.00 1.00 CK5PE 042 1.00 0.94
048 1.00 1.00 CK5PT 042 1.00 0.95
CK5A/CK5BW 048 1.00 1.00 048 1.00 0.94
CK5PA 042 1.00 1.00 COILS + 315(A,J)AV060110 VARIABLE SPEED FURNACE
048 1.00 1.00 CC5A/CD5AA 042 0.99 0.94
CK5PE 042 0.98 0.97 CC5A/CD5AC 048 0.99 0.94
CK5PT 042 1.00 1.00 CC5A/CD5AW 042 0.98 0.93
048 1.00 1.00 048 1.00 0.94
CK5PW 048 1.00 1.00 CD5AA 048 1.00 0.94
F(A,B)4(A,B)N(F,B,C) 042 1.00 1.00 CE3AA 042 1.00 0.94
048 1.01 0.99 048 1.01 0.95
FE4ANB 006 1.02 0.89 CK3BA 042 1.00 0.95
FE4ANF 003 0.98 0.92 048 1.00 0.93
005 1.01 0.91 CK5A/CK5BA 042 1.00 0.95
FG3AAA 048 0.99 0.99 048 1.00 0.94
FK4(C,D)NB 006 1.02 0.89 CK5A/CK5BE 042 1.00 0.95
FK4(C,D)NF 003 0.98 0.91 CK5A/CK5BT 042 1.00 0.95
005 1.01 0.91 048 1.00 0.94
FV4(A,B)NB 006 1.02 0.89 CK5A/CK5BW 048 1.00 0.93
FV4(A,B)NF 003 0.98 0.92 CK5PA 042 1.00 0.95
005 1.01 0.91 048 1.00 0.94
FX4(A,B)NF 042 0.99 1.00 CK5PE 042 1.00 0.95
048 1.00 1.00 CK5PT 042 1.00 0.95
COILS + 315(A,J)AV048090 VARIABLE SPEED FURNACE 048 1.00 0.94
CC5A/CD5AA 042 0.99 0.94 CK5PW 048 1.00 0.93
CC5A/CD5AC 048 0.99 0.94 — — —
