Display installation
39
Display installation
After unpacking the display
Important:
In the factory, the height-positioning system in the display foot
is blocked with a red clip to prevent damage during
transportation.
Before installing the display, you must remove this clip.
Figure 8
To remove the clip:
1. Position the display with its rear side facing you.
2. Pull the red clip out of the fixation holes in the foot.
3. Keep the clip in case the display needs to be shipped later.
Adjust the panel orientation
You can change the orientation of the panel at any time, but it
is more convenient to select landscape or portrait orientation
before connecting the cables.
Clip
