Barco E-2320 C (SE) User Manual
Page 37
Installing your Barco display controller
37
Figure 7:
11.
Reconnect any cables you have disconnected and plug in the
computer’s power cord.
12.
Turn on the display(s) and then your computer.
Turning on your system
MXRT 5100 and MXRT 7100 Baseplate
X
Head 1 – DVI-I Connection
Y
Stereographics Connection
Note:
This option is not supported in Nio Systems.
Z
Head 2 – DVI-I Connection
WARNING - Turn on your display(s) before you turn on
your computer. Failure to do so could damage your dis-
play(s).
