Barco E-2320 C (SE) User Manual
Page 27
Parts, controls and connectors
27
Rear
Figure 2
1. Connector compartment cover
To get access to the connectors, remove the cover by
pulling down the 2 clips at the top of the cover.
2. Tilt & swivel foot cover
This cover is packed in a separate box when the display is
shipped to the customer.
3. Tilt & swivel foot
4. DVI (digital) video input
5. D-Sub 15 (VGA) video input
6. USB downstream port
USB 1.1 standard is supported.
When the display is connected to the PC USB bus, you can
connect USB devices, such as keyboard, mouse, digital
camera, to this connector.
⌦
