—5—
SPECIFICATIONS Continued
* Permissible limits of the voltage range at which the unit will operate satisfactorily. Operation outside these limits may result in unit failure.
† If wire is applied at ambient greater than 30°C (86°F), consult Table 310-16 of the NEC (ANSI/NFPA 70).
The ampacity of nonmetallic-sheathed cable (NM), trade name ROMEX, shall be that of 60°C (140°F) conductors, per the NEC (ANSI/NFPA 70) Article
336-26. If other than uncoated (non-plated), 60 or 75°C (140 or 167°F) insulation, copper wire (solid wire for 10 AWG and smaller, stranded wire for larger
than 10 AWG) is used, consult applicable tables of the NEC (ANSI/NFPA 70).
‡ Length shown is as measured 1 way along wire path between unit and service panel for a voltage drop not to exceed 2%.
** See low-ambient controller Installation Instructions for application.
†† Fan motor with ball bearings required.
N/A — Not Applicable.
NOTE: Copper wire must be used from service disconnect to unit. All motors/compressors contain internal overload protection.
UNIT SIZE-SERIES 042-D/E 048-D/E 060-D/E
Operating Weight (Lb) 247 295 331
ELECTRICAL
Unit Volts—Hertz—Phase 208/230—60—1
Operating Voltage Range* 187—253
Compressor— Rated Load Amps 18.6 20.5 27.6
Locked Rotor Amps 105.0 109.0 158.0
Condenser Fan Motor—Full Load Amps 1.1 1.4 1.4
Min Unit Ampacity for Wire Sizing 24.4 27.0 35.9
Min Wire Size (60°C Copper) AWG† 10 10 8
Min Wire Size (75°C Copper) AWG† 10 10 8
Max Wire Length (Ft) (60°C Copper)‡ 80 73 85
Max Wire Length (Ft) (75°C Copper)‡ 76 70 80
Max Branch Circuit Fuse or
Circuit Breaker Size (Amps) 40 40 60
COMPRESSOR & REFRIGERANT
Compressor— Type Scroll
Manufacturer Copeland
Temperature & Current Protection Internal Line Break
Refrigerant— Type Puron® (R-410A)
Amount (Lb) 8.75 10.13 12.00
CONDENSER COIL & FAN
Coil Face Area (Sq Ft) 18.2 18.2 18.2
Fins per In.—Rows—Circuits 25—1—3 20—2—5 20—2—5
Fan Motor—HP (PSC) & RPM 1/5 & 825 1/4 & 1100 1/4 & 1100
Volts—Hertz—Phase 208/230—60—1
Condenser Airflow (CFM) 2800 3300 3300
OPTIONAL EQUIPMENT
Support Feet KSASF0101AAA
Coastal Filter KAACF0201MED
Time Delay Relay KAATD0101TDR
Cycle Protector KSACY0101AAA
Crankcase Heater KAACH1201AAA Standard
Start Assist—Capacitor/Relay Type KSAHS1501AAA KSAHS1601AAA
Start Assist—PTC Type KAACS0201PTC
TXV (Hard Shutoff) KSATX0301HSZ KSATX0401HSZ KSATX0501HSZ
Piston Body KSAPX0101PIS
Filter Drier (Suction Line) KH45LG141 (RCD)
Evaporator Freeze Thermostat** KAAFT0101AAA
Liquid-Line Solenoid Valve KAALS0201LLS Standard
Winter Start Control** KAAWS0101AAA
Low-Ambient Pressure Switch KSALA0301410
Low-Ambient Controller P251-0083 (RCD)
MotorMaster® Control†† 32LT660004 (RCD)
Ball Bearing Fan Motor HC38GE230 (RCD) HC40GE230 (RCD)
Thermostat—Auto Changeover,
Non-Programmable, °F/°C,
1-Stage Heat, 1-Stage Cool
TSTATBBNAC01-B
Thermostat—Auto Changeover,
7-Day Programmable, °F/°C,
1-Stage Heat, 1-Stage Cool
TSTATBBPAC01-B
Thermidistat™ Control—
Programmable/Non-Programmable Thermostat with
Humidity Control
TSTATBBPRH01-B
Builder’s Thermostat—Manual Changeover,
Non-Programmable, °F/°C,
1-Stage Heat, 1-Stage Cool
TSTATBBBAC01-B
Outdoor Air Temperature Sensor TSTATXXSEN01-B
Backplate for Non-Programmable Thermostat TSTATXXNBP01
Backplate for Programmable Thermostat TSTATXXPBP01
Backplate for Builder’s Thermostat TSTATXXBBP01
Thermostat Conversion Kit (4 to 5 wire)—10 Pack TSTATXXCNV10
