CONDENSER ONLY RATINGS* Continued
* ARI listing applies only to systems shown in Ratings and Performance table.
KW — Total Power (Kw)
SDT — Saturated Temperature Leaving Compressor (°F)
SST — Saturated Temperature Entering Compressor (°F)
TCG — Gross Cooling Capacity (1000 Btuh).
SST
°F
CONDENSER ENTERING AIR TEMPERATURES °F
55 65 75 85 95 105 115 125
550A042-D/E
30
TCG
SDT
KW
41.4
72.3
1.85 39.2
82.0
2.10 37.0
91.8
2.39 34.8
102.0
2.72
32.5
111.0
3.07
30.2
121.0
3.46
27.8
130.0
3.89
25.3
140.0
4.36
35
TCG
SDT
KW
45.4
73.7
1.86 43.0
83.4
2.12 40.6
93.1
2.41 38.2
103.0
2.74
35.7
112.0
3.09
33.2
122.0
3.49
30.6
131.0
3.92
27.8
141.0
4.39
40
TCG
SDT
KW
49.6
75.2
1.88 47.0
84.8
2.14 44.5
94.4
2.43 41.8
104.0
2.76
39.1
114.0
3.12
36.4
123.0
3.51
33.5
133.0
3.94
30.5
142.0
4.41
45
TCG
SDT
KW
54.0
76.7
1.89 51.3
86.3
2.16 48.5
95.9
2.45 45.7
106.0
2.78
42.7
115.0
3.14
39.8
125.0
3.54
36.7
134.0
3.97
33.3
143.0
4.44
50
TCG
SDT
KW
58.8
78.4
1.92 55.8
87.9
2.18 52.8
97.4
2.47 49.7
107.0
2.80
46.6
117.0
3.17
43.3
126.0
3.57
39.9
135.0
4.00
36.3
144.0
4.47
55
TCG
SDT
KW
63.8
80.2
1.94 60.6
89.6
2.20 57.4
99.1
2.50 54.0
109.0
2.83
50.6
118.0
3.20
47.1
127.0
3.60
43.4
137.0
4.03
39.5
145.0
4.50
550A048-D/E
30
TCG
SDT
KW
45.8
72.0
2.11 43.3
82.0
2.40 40.9
92.0
2.73 38.5
102.0
3.09
36.0
112.0
3.52
33.6
122.0
3.98
31.0
132.0
4.51
28.4
142.0
5.09
35
TCG
SDT
KW
50.6
72.0
2.10 47.9
82.0
2.39 45.2
92.0
2.71 42.6
102.0
3.08
39.9
112.0
3.49
37.2
122.0
3.96
34.4
132.0
4.48
31.5
142.0
5.06
40
TCG
SDT
KW
55.7
72.3
2.10 52.8
82.1
2.38 49.9
92.0
2.70 47.0
102.0
3.06
44.1
112.0
3.47
41.1
122.0
3.93
38.1
132.0
4.45
34.9
142.0
5.02
45
TCG
SDT
KW
60.9
73.6
2.13 57.8
83.2
2.40 54.7
92.7
2.71 51.7
102.0
3.06
48.6
112.0
3.46
45.4
122.0
3.91
42.1
132.0
4.42
38.5
142.0
4.99
50
TCG
SDT
KW
66.3
75.1
2.17 63.0
84.6
2.44 59.7
94.1
2.75 56.4
104.0
3.09
53.1
113.0
3.48
49.8
123.0
3.92
46.2
132.0
4.41
42.5
142.0
4.96
55
TCG
SDT
KW
72.1
76.7
2.21 68.5
86.1
2.48 65.0
95.6
2.79 61.4
105.0
3.14
57.8
114.0
3.52
54.2
124.0
3.95
50.5
133.0
4.43
46.5
143.0
4.96
550A060-D/E
30
TCG
SDT
KW
57.0
73.9
2.80 54.0
83.4
3.19 51.1
93.1
3.63 48.1
103.0
4.12
45.1
112.0
4.67
42.1
122.0
5.29
39.0
132.0
5.99
35.6
142.0
6.77
35
TCG
SDT
KW
62.4
75.4
2.85 59.2
84.9
3.24 56.0
94.5
3.67 52.8
104.0
4.16
49.6
114.0
4.71
46.3
123.0
5.32
43.0
133.0
6.00
39.4
142.0
6.76
40
TCG
SDT
KW
68.2
77.1
2.91 64.7
86.6
3.29 61.2
96.0
3.73 57.7
105.0
4.22
54.3
115.0
4.76
50.7
124.0
5.37
47.1
134.0
6.04
43.3
143.0
6.78
45
TCG
SDT
KW
74.3
79.0
2.97 70.5
88.3
3.36 66.8
97.7
3.79 63.0
107.0
4.28
59.3
117.0
4.83
55.4
126.0
5.43
51.4
135.0
6.10
47.3
144.0
6.84
50
TCG
SDT
KW
80.7
80.9
3.03 76.7
90.2
3.42 72.7
99.5
3.86 68.6
109.0
4.36
64.5
118.0
4.90
60.3
127.0
5.50
56.0
137.0
6.17
51.5
146.0
6.90
55
TCG
SDT
KW
87.6
83.0
3.11 83.2
92.2
3.50 78.9
101.0
3.94
74.4
111.0
4.44
70.0
120.0
4.98
65.5
129.0
5.59
60.8
138.0
6.25
55.9
147.0
6.98
