—14—
COMBINATION RATINGS Continued
* Tested combination.
† In most cases, only one method should be used to achieve TDR function. Using more than one method in a system may cause degradation in performance.
Use either the accessory Time-Delay Relay KAATD0101TDR or a furnace equipped with TDR. Most Bryant furnaces are equipped with TDR.
‡ Based on computer simulation. TXV must be Puron® compatible and hard shutoff type.
** Ratings shown are with FK4C R-22 TXV replaced with Puron® TXV.
†† Ratings shown are with FK4C R-22 TXV replaced with Piston Body Kit and piston shipped with outdoor unit.
EER
— Energy Efficiency Ratio
LLS — Liquid-Line Solenoid Valve
SEER — Seasonal Energy Efficiency Ratio
TDR
— Time-Delay Relay
TXV — Thermostatic Expansion Valve
NOTES: 1. Ratings are net values reflecting the effects of circulating fan motor heat. Supplemental electric heat is not included.
2. Tested outdoor/indoor combinations have been tested in accordance with DOE test procedures for electric air conditioners. Ratings for other com-
binations are determined under DOE computer simulation procedures.
3. Determine actual CFM values obtainable for your system by referring to fan performance data in fan coil or furnace coil literature.
4. Do not apply with capillary tube coils as performance and reliability are significantly affected.
UNIT
SIZE-SERIES
INDOOR
MODEL
TOT.
CAP.
BTUH
FACTORY-
SUPPLIED
ENHANCE-
MENT
SEER
EER
Standard
Rating
Bryant Gas
Furnace or
Accessory
TDR†
Accessory
TXV‡
048-D, E
COILS + 355MAV060120 VARIABLE SPEED FURNACE
CC5A/CD5AA060 46,500 TDR 13.00 — 13.00 11.55
CC5A/CD5AC048 45,000 TDR 12.50 — 12.50 11.20
CC5A/CD5AW048 46,000 TDR 13.00 — 13.00 11.50
CC5A/CD5AW060 47,000 TDR 13.50 — 13.50 12.00
CD5AA048 46,000 TDR 13.00 — 13.00 11.50
CE3AA048 46,500 TDR 13.00 — 13.00 11.55
CE3AA060 47,000 TDR 13.20 — 13.20 11.95
CK3BA048 46,000 TDR 13.00 — 13.00 11.60
CK3BA060 46,500 TDR 13.00 — 13.00 11.80
CK5A/CK5BA060 46,500 TDR 13.00 — 13.00 11.80
CK5A/CK5BW048 46,000 TDR 13.00 — 13.00 11.60
CK5A/CK5BX060 47,500 TDR 13.50 — 13.50 12.15
060-D, E
CK3BA060 58,000 LLS — 12.50 — 10.95
CJ5A/CK5A/CK5BX060* 59,000 LLS — 13.00 — 11.10
CJ5A/CK5A/CK5BA060 58,000 LLS — 12.50 — 10.95
F(A,B)4AN(F,B,C)060 58,000 LLS & TDR 12.20 — — 10.60
FB4ANB070 59,000 LLS & TDR 13.00 — — 11.10
FK4CNB006** 59,000 LLS & TDR 13.25 — — 11.55
FK4CNB006†† 59,000 LLS & TDR 13.25 — — 11.55
FV4ANB006 58,000 LLS, TDR, & TXV 13.25 — — 11.55
FX4ANB060 58,000 LLS, TDR, & TXV 12.50 — — 10.95
COILS + 333(B,J)AV060100 VARIABLE SPEED FURNACE
CK3BA060 57,500 LLS & TDR 13.00 — — 11.20
CK5A/CK5BA060 57,500 LLS & TDR 13.00 — — 11.20
CK5A/CK5BX060 58,500 LLS & TDR 13.25 — — 11.50
COILS + 333(B,J)AV060120 VARIABLE SPEED FURNACE
CK3BA060 57,500 LLS & TDR 12.75 — — 11.05
CK5A/CK5BA060 57,500 LLS & TDR 12.75 — — 11.05
CK5A/CK5BX060 58,500 LLS & TDR 13.00 — — 11.35
COILS + 355MAV060100 VARIABLE SPEED FURNACE
CK3BA060 57,000 LLS & TDR 12.50 — — 11.00
CK5A/CK5BA060 57,000 LLS & TDR 12.50 — — 11.00
CK5A/CK5BX060 58,000 LLS & TDR 13.00 — — 11.25
COILS + 355MAV060120 VARIABLE SPEED FURNACE
CK3BA060 57,000 LLS & TDR 12.75 — — 11.05
CK5A/CK5BA060 57,000 LLS & TDR 12.75 — — 11.05
CK5A/CK5BX060 58,000 LLS & TDR 13.00 — — 11.30
