—20—
DETAILED COOLING CAPACITIES* Continued
See notes on page 24.
EVAP
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
Sys
Kw**
Capacity
MBtuh†
Total
Sys
Kw**
Capacity
MBtuh†
Total
Sys
Kw**
Capacity
MBtuh†
Total
Sys
Kw**
Capacity
MBtuh†
Total
Sys
Kw**
Capacity
MBtuh†
Total
Sys
Kw** Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
550A042-D, E Outdoor Section With CD5AA048 Indoor Section
1225
72 46.7 22.7 2.49 45.2 22.3 2.77 43.3 21.6 3.09 41.2 20.9 3.44 38.8 20.1 3.83 36.0 19.2 4.26
67 44.0 29.5 2.47 42.3 28.9 2.75 39.8 27.8 3.05 37.7 27.1 3.40 35.4 26.3 3.79 31.4 24.7 4.18
63†† 40.5 28.7 2.44 37.8 27.5 2.70 35.0 26.3 3.00 32.0 25.0 3.32 30.2 24.3 3.70 27.8 23.3 4.11
62 39.3 35.4 2.43 36.7 34.1 2.69 33.9 32.7 2.98 31.1 30.9 3.31 29.5 29.5 3.69 27.9 27.9 4.11
57 36.4 36.4 2.40 34.3 34.3 2.67 32.1 32.1 2.96 30.8 30.8 3.30 29.4 29.4 3.69 27.7 27.7 4.11
1400
72 47.1 23.3 2.55 45.8 23.0 2.83 43.9 22.5 3.15 41.8 21.8 3.51 39.3 21.1 3.90 36.5 20.2 4.33
67 44.3 30.5 2.52 42.7 30.2 2.81 40.5 29.4 3.12 38.4 28.8 3.47 35.9 27.9 3.85 31.7 26.4 4.25
63†† 42.1 30.7 2.51 39.3 29.5 2.78 36.4 28.3 3.07 33.6 27.1 3.40 31.8 26.3 3.79 27.9 24.7 4.18
62 40.5 37.9 2.50 37.8 36.5 2.76 35.0 34.8 3.06 32.7 32.7 3.39 31.2 31.2 3.78 29.5 29.5 4.21
57 38.1 38.1 2.48 36.2 36.2 2.74 35.0 35.0 3.05 33.6 33.6 3.40 32.2 32.2 3.79 29.3 29.3 4.20
1575
72 47.5 23.9 2.61 46.2 23.7 2.90 44.4 23.2 3.22 41.8 22.4 3.56 39.5 21.8 3.95 36.8 21.1 4.40
67 44.9 31.9 2.58 43.0 31.5 2.86 41.1 31.1 3.18 38.8 30.3 3.53 36.3 29.6 3.92 32.0 28.0 4.32
63†† 42.5 32.0 2.57 40.5 31.4 2.85 37.6 30.1 3.15 35.0 29.1 3.48 33.1 28.3 3.87 27.9 26.0 4.24
62 41.6 40.2 2.57 38.9 38.5 2.83 36.5 36.5 3.13 35.4 35.4 3.49 32.7 32.7 3.86 30.7 30.7 4.29
57 40.7 40.7 2.56 39.0 39.0 2.83 37.6 37.6 3.15 35.8 35.8 3.49 33.5 33.5 3.87 30.7 30.7 4.29
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CD5AA 048 1.00 1.00 CD5AA 048 1.00 0.93
CC5A/CD5AA 042 1.00 1.00 CE3AA 042 1.00 0.94
CC5A/CD5AC 048 0.99 1.00 048 1.01 0.94
CC5A/CD5AW 042 0.99 1.00 CK3BA 042 0.99 0.94
048 1.00 1.00 048 1.00 0.94
CE3AA 042 1.01 1.00 CK5A/CK5BA 042 0.99 0.94
048 1.01 1.00 048 1.00 0.94
CF5AA 048 1.00 1.00 COILS + 333(B,J)AV060100 VARIABLE SPEED FURNACE
CK3BA 042 1.00 1.00 CC5A/CD5AA 042 1.00 0.92
048 1.00 1.00 CC5A/CD5AC 048 0.99 0.91
CK5A/CK5BA 042 1.00 1.00 CC5A/CD5AW 042 0.99 0.92
048 1.00 1.00 048 1.00 0.92
CK5A/CK5BN 042 0.98 1.00 CD5AA 048 1.00 0.92
048 0.98 1.00 CE3AA 042 1.01 0.92
CK5A/CK5BW 048 1.00 1.00 048 1.01 0.93
F(A,B)4AN(F,B) 042 1.00 1.00 CK3BA 042 1.00 0.92
048 1.01 1.00 048 1.00 0.92
FG3AAA 048 0.99 1.00 CK5A/CK5BA 042 1.00 0.92
FK4CNB 006‡‡ 1.02 0.90 CK5A/CK5BW 048 1.00 0.92
006*** 1.01 0.92 COILS + 333(B,J)AV060120 VARIABLE SPEED FURNACE
FK4CNF 003‡‡ 0.98 0.92 CC5A/CD5AA 042 1.00 0.94
005‡‡ 1.01 0.91 CC5A/CD5AC 048 0.98 0.93
FV4ANB 006 1.02 0.90 CC5A/CD5AW 042 0.99 0.93
FV4ANF 003 0.98 0.92 048 1.00 0.93
005 1.01 0.91 CD5AA 048 1.00 0.93
FX4ANF 042 0.99 1.00 CE3AA 042 1.00 0.94
048 1.00 1.01 048 1.01 0.94
COILS + 333(B,J)AV048080 VARIABLE SPEED FURNACE CK3BA 042 1.00 0.93
CC5A/CD5AA 042 0.99 0.94 048 1.00 0.93
CC5A/CD5AC 048 0.98 0.93 CK5A/CK5BA 042 1.00 0.93
CC5A/CD5AW 042 0.99 0.94 CK5A/CK5BW 048 1.00 0.93
048 1.00 0.93 — — —
