Detailed cooling capacities* continued – Bryant DELUXE 13 SEER 550A User Manual
Page 21
—21—
DETAILED COOLING CAPACITIES* Continued
See notes on page 24.
EVAP
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75
85
95
105
115
125
CFM
EWB
Capacity
MBtuh†
Total
Sys
Kw**
Capacity
MBtuh†
Total
Sys
Kw**
Capacity
MBtuh†
Total
Sys
Kw**
Capacity
MBtuh†
Total
Sys
Kw**
Capacity
MBtuh†
Total
Sys
Kw**
Capacity
MBtuh†
Total
Sys
Kw**
Total Sens‡
Total Sens‡
Total Sens‡
Total Sens‡
Total Sens‡
Total Sens‡
550A042-D, E Outdoor Section With CD5AA048 Indoor Section Continued
1225
72
46.7
22.7
2.49
45.2
22.3
2.77
43.3
21.6
3.09
41.2
20.9
3.44
38.8
20.1
3.83
36.0
19.2
4.26
67
44.0
29.5
2.47
42.3
28.9
2.75
39.8
27.8
3.05
37.7
27.1
3.40
35.4
26.3
3.79
31.4
24.7
4.18
63†† 40.5
28.7
2.44
37.8
27.5
2.70
35.0
26.3
3.00
32.0
25.0
3.32
30.2
24.3
3.70
27.8
23.3
4.11
62
39.3
35.4
2.43
36.7
34.1
2.69
33.9
32.7
2.98
31.1
30.9
3.31
29.5
29.5
3.69
27.9
27.9
4.11
57
36.4
36.4
2.40
34.3
34.3
2.67
32.1
32.1
2.96
30.8
30.8
3.30
29.4
29.4
3.69
27.7
27.7
4.11
1400
72
47.1
23.3
2.55
45.8
23.0
2.83
43.9
22.5
3.15
41.8
21.8
3.51
39.3
21.1
3.90
36.5
20.2
4.33
67
44.3
30.5
2.52
42.7
30.2
2.81
40.5
29.4
3.12
38.4
28.8
3.47
35.9
27.9
3.85
31.7
26.4
4.25
63†† 42.1
30.7
2.51
39.3
29.5
2.78
36.4
28.3
3.07
33.6
27.1
3.40
31.8
26.3
3.79
27.9
24.7
4.18
62
40.5
37.9
2.50
37.8
36.5
2.76
35.0
34.8
3.06
32.7
32.7
3.39
31.2
31.2
3.78
29.5
29.5
4.21
57
38.1
38.1
2.48
36.2
36.2
2.74
35.0
35.0
3.05
33.6
33.6
3.40
32.2
32.2
3.79
29.3
29.3
4.20
1575
72
47.5
23.9
2.61
46.2
23.7
2.90
44.4
23.2
3.22
41.8
22.4
3.56
39.5
21.8
3.95
36.8
21.1
4.40
67
44.9
31.9
2.58
43.0
31.5
2.86
41.1
31.1
3.18
38.8
30.3
3.53
36.3
29.6
3.92
32.0
28.0
4.32
63†† 42.5
32.0
2.57
40.5
31.4
2.85
37.6
30.1
3.15
35.0
29.1
3.48
33.1
28.3
3.87
27.9
26.0
4.24
62
41.6
40.2
2.57
38.9
38.5
2.83
36.5
36.5
3.13
35.4
35.4
3.49
32.7
32.7
3.86
30.7
30.7
4.29
57
40.7
40.7
2.56
39.0
39.0
2.83
37.6
37.6
3.15
35.8
35.8
3.49
33.5
33.5
3.87
30.7
30.7
4.29
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section
Size
Cooling
Indoor
Section
Size
Cooling
Capacity
Power
Capacity
Power
COILS + 355MAV042040 VARIABLE SPEED FURNACE
CC5A/CD5AC
048
0.99
0.96
CC5A/CD5AA
042
1.00
1.01
CC5A/CD5AW
042
0.99
0.98
CC5A/CD5AC
048
0.99
0.99
048
1.00
0.96
CC5A/CD5AW
042
0.99
1.00
CC5AA
048
1.00
0.96
048
1.00
0.99
CE3AA
042
1.01
0.98
CD5AA
048
1.00
0.99
048
1.01
0.98
CE3AA
042
0.99
1.01
COILS + 355MAV060100 VARIABLE SPEED FURNACE
048
0.99
1.01
CC5A/CD5AA
042
1.00
0.98
COILS + 355MAV042060 VARIABLE SPEED FURNACE
CC5A/CD5AC
048
0.99
0.96
CC5A/CD5AA
042
1.00
1.00
CC5A/CD5AW
042
0.99
0.98
CC5A/CD5AC
048
0.99
0.99
048
1.00
0.96
CC5A/CD5AW
042
0.99
1.00
CC5AA
048
1.00
0.96
048
0.99
0.99
CE3AA
042
1.01
0.98
CD5AA
048
0.99
0.99
048
1.01
0.98
CE3AA
042
1.00
1.00
CK3BA
042
1.00
0.98
048
1.00
1.01
048
1.00
0.97
COILS + 355MAV042080 VARIABLE SPEED FURNACE
CK5A/CK5BA
042
1.00
0.98
CC5A/CD5AA
042
1.00
0.98
CK5A/CK5BW
048
1.00
0.97
CC5A/CD5AC
048
0.99
0.97
COILS + 355MAV060120 VARIABLE SPEED FURNACE
CC5A/CD5AW
042
0.99
0.98
CC5A/CD5AA
042
1.00
0.98
048
1.00
0.97
CC5A/CD5AC
048
0.99
0.98
CD5AA
048
1.00
0.97
CC5A/CD5AW 042
0.99
0.98
CE3AA
042
1.01
0.98
048
1.00
0.96
048
1.01
0.99
CD5AA
048
1.00
0.96
CK3BA
042
1.00
0.99
CE3AA
042
1.01
0.98
048
1.00
0.98
048
1.01
0.98
CK5A/CK5BA
042
1.00
0.99
CK3BA
042
1.00
0.97
048
1.00
0.98
048
1.00
0.96
COILS + 355MAV060080 VARIABLE SPEED FURNACE
CK5A/CK5BA
042
1.00
0.97
CC5A/CD5AA
042
1.00
0.98
CK5A/CK5BW
048
1.00
0.96
