—3—
RECOMMENDED TUBE DIAMETERS
* For tube sets greater than 50 ft, consult Residential Split System Application Guideline and Service Manual.
CHECK-FLO-RATER® PISTON
* Piston listed is for any approved non-capillary tube coil combination. Piston is shipped
with outdoor unit and must be installed in an approved indoor coil.
CHARGING SUBCOOLING (TXV-TYPE EXPANSION DEVICE*)
* Must be a Puron® approved hard shutoff TXV.
UNIT
SIZE
Liquid Tube Diameter (In.) Vapor Tube Diameter (In.)
0 to 50 Ft
Tube Length Long-Line Applications*
0 to 50 Ft
Tube Length
Long-Line Applications*
(Maximum Diameter)
024
3/8 3/8
5/8 7/8
030, 036 3/4 7/8
042, 048 7/8 1-1/8
060 1-1/8 1-1/8
UNIT SIZE–SERIES
PISTON*
IDENTIFICATION NO.
024-D, E 61
030-D, E 63
036-D, E 70
042-D, E 73
048-D, E 78
060-D, E 96
UNIT SIZE–SERIES REQUIRED SUBCOOLING (°F)
024-D, E 13
030-D, E 12
036-D, E 11
042-D, E 12
048-D, E 11
060-D, E 12
M
A N
U F A
C T U R E R
CE
RT IFIED TO ARI
AS
C O M
P L Y
IN
G
W
IT
H
A RI
STANDARD 21
0
U N IT A R Y
AIR CO
N D IT IO
N IN
G
EQUIPMENT
CERTIFICATION APPLIES ONLY
WHEN THE COMPLETE SYSTEM
IS LISTED WITH ARI.
REGISTERED QUALITY SYSTEM
As an ENERGY STAR®
partner, Bryant Heating &
Cooling Systems has
determined that this prod-
uct meets the ENERGY
STAR® guidelines for
energy efficiency.
