Installation

Step 4 Powering Up the Systems (required)

4.1 Attach the power adapter to the DC power jack labeled “5V, 2.5A” on the

back of the Switch. Only use the power adapter supplied with the Switch.
(Refer to diagram below.)

4.2 Power on your computers and your monitor. All computers can be

powered on simultaneously.

Note: Your computers should recognize the Switch and automatically install the
HID USB driver if necessary.

When you power on your computers, the Switch emulates both a mouse
and keyboard on each port and allows your computers to boot normally. The
computer connected to port “1” will be displayed on the monitor. Check to see
that the keyboard, monitor, and mouse are working normally. Proceed to do this
with all occupied ports to verify that all computers are connected and responding
correctly. If you encounter an error, check your cable connections for that
computer and reboot. If the problem persists, please refer to the Troubleshooting
section in this User Manual.
