Overview
Specifications
Part No.: F1DN102U, F1DN104U, F1DN108U
Enclosure: Metal enclosure with high-impact plastic faceplate
Power Requirements: 5V DC, 2.5A (minimum) power adapter with
center-pin-positive polarity
4
AC Input: 100 to 240VAC
Interchangeable AC Plugs: 4 (U.S., U.K., Europe, Australia)
No. of Users Supported: 1
No. of Computers Supported: 2, 4, and 8 respectively for 2-, 4-, and 8-port models
Monitors Supported:
CRT and LCD (with VGA support)
Resolution Support: Up to 1920x1440@75Hz
Console Keyboard Input: USB Type A
Console Mouse Input: USB Type A
Console Monitor Port: HDDB15 female (VGA)
CPU Keyboard/Mouse Ports: USB Type B
CPU Monitor Ports:
HDDB15 male (VGA)
Port Selectors: 2, 4, and 8 respectively for 2-, 4-, and 8-port models
LED Indicators: 2, 4, and 8 respectively for 2-, 4-, and 8-port models
Operating Temp: 32° to 104° F (0° to 40° C)
Storage Temp: -4° to 140° F (-20° to 60° C)
Humidity: 0-80% RH, non-condensing
Warranty: 3 years
Dimensions: (F1DN102U) 11 x 1.75 x 6 in. (279 x 45 x 150mm)
(F1DN104U) 11 x 1.75 x 6 in. (279 x 45 x 150mm)
(F1DN108U) 17.25 x 1.75 x 7.5 in. (438 x 45 x 190mm)
Weight: (F1DN102U) 2.5 lbs. (1.1kg.)
(F1DN104U) 2.5 lbs. (1.1kg.)
(F1DN108U) 4.5 lbs. (2.0kg.)
Made in the USA of imported parts
4 The Switch includes a 5-volt, 3-Amp power adapter, but only requires a minimum of 2.5 Amps.
