Installation
Bracket Installation (F1DN102U and F1DN104U)
The 2- and 4-Port Switches can be installed into a 19-inch rack using an optional
Rack-Mount Kit, sold separately (Belkin part number F1D005).
1.1 Attach the Rack-Mount Bracket to the Switch using the Phillips screws
provided. (Refer to diagram below.)
1.2 Mount the Switch to the rack rails. (Refer to diagram below.)
Your Switch is now mounted securely to the rack and you are ready to
connect your console.
