Customising preferences

10

Chapter

54

Engb

Setting the video signal

You can select the suitable video signal setting
for your rear view camera.

p

As this function is initially set to “Auto”,

the product will automatically adjust the
video signal setting.
However, the screen may turn black or im-
ages may not be displayed properly when
Auto” has been selected. Normally, select
the appropriate video signal.

1 Display the “System” screen.

Ü

For details, refer to Customising the

system settings on page 48.

2 Tap [Video Signal Setting].
The “Video Signal Setting” screen appears.

3 Tap or

to select the desired video

signal.
Auto
(default) — PALNTSCPAL-M

PAL-N

SECAM

Adjusting the picture

You can adjust the brightness, contrast, col-
our, hue, dimmer and temperature for each
source and rear view camera.
1 Playback the source you want to adjust
the picture.
2 Display the “System” screen.

Ü

For details, refer to Customising the

system settings on page 48.

3 Tap [Picture Adjustment].
The picture adjustment screen appears.

4 If you are adjusting the picture adjust-
ment, select the source.

Rear View: Adjusts the picture for the

rear view camera.

Source: Adjusts the picture for the

source. The current source name is dis-
played on the picture adjustment screen.

5 Tap any of the following touch panel
keys to select the function to be adjusted.
Picture adjustment items are displayed.

Brightness: Adjusts the black intensity.
Contrast: Adjusts the contrast.
Color: Adjusts the colour saturation.
Hue: Adjusts the tone of colour (red or

green is emphasized).

Dimmer: Adjusts the brightness of the

display.

Temperature: Adjusts the colour tem-

perature, resulting in a better white bal-
ance.

p

You can adjust “Hue” only when “Video

Signal Setting” is set to “NTSC”.

p

With some rear view cameras, picture ad-

justment may not be possible.
