Plugging in
Important
• Before making or changing the connections, switch off
the power and disconnect the power cord from the AC
outlet.
After you’ve finished making all connections, plug the unit
into an AC outlet.
1 Plug the supplied AC adapter into the DC IN
socket on the back of the unit.
2 Plug the supplied power cord into the AC
adapter then plug the other end into an AC
outlet.
ANTENNA
LAN
(10/100)
VIDEO
OUT
DC IN
19 V
FM75
To AC outlet
AC adapter
(supplied)
This unit’s rear panel
Power code (supplied)
