The System Setup menu 06
42
En
The Input Assign menu
You only need to make settings in the Input
Assign menu if you didn’t hook up your
equipment according to the default settings for
the component video inputs.
• Default settings:
COMP 1 – BD
COMP 2 – DVD
If you didn’t make component video
connections according to the defaults above,
you must assign the numbered input to the
component you’ve connected (or else you may
see the video signal of a different component).
For more on this, see Using the component
video jacks on page 24.
1 Select ‘IN ASSIG’ from the System Setup
menu.
2 Select ‘COMP. IN’ from the IN ASSIG
menu.
3 Use / to select the number of the
component video input to which you’ve
connected your video component.
The numbers correspond with the numbers
beside the inputs on the rear of the receiver.
4 Select the component that corresponds
with the one you connected to that input.
• Use the
/ buttons and ENTER to select
BD, DVD, TV, DVR or OFF.
• If you assign a component input to a
certain function, any component inputs
previously assigned to that function will
automatically be switched off.
• Make sure you have connected the audio
from the component to the corresponding
inputs on the rear of the receiver.
• If you connect any source component to
the receiver using a component video
input, you should also have your TV
connected to this receiver’s
COMPONENT
VIDEO OUT jacks.
• For the assignment of the digital signal
inputs, see Choosing the input signal on
page 38.
The Pre Out Setting
Specify either using the surround back speaker
or the front height speaker connection with the
PRE OUT outputs. An additional amplifier is
required for the speaker connection.
• Default setting: SURR.BACK (Surround
back)
1 Select ‘PRE OUT’ from the System Setup
menu.
2 Select which speaker to connect to the
PRE OUT outputs using
/.
• SURR.BACK – Connect the surround back
speaker.
• HEIGHT – Connect the front height
speaker.
