Specifications
General
Power source ............................. 14.4 V DC (10.8 V to 15.1 V
allowable)
Grounding system ................... Negative type
Maximum current consumption
..................................................... 10.0 A
Dimensions (W × H × D):
DIN
Chassis ......................................... 178 mm × 50 mm ×
165 mm
Nose ............................................... 188 mm × 58 mm × 17 mm
(DEH-X9600BT)
Nose ............................................... 188 mm × 58 mm × 18 mm
(DEH-X8600BT)
D
Chassis ......................................... 178 mm × 50 mm ×
165 mm
Nose ............................................... 170 mm × 46 mm × 17 mm
(DEH-X9600BT)
Nose ............................................... 170 mm × 46 mm × 18 mm
(DEH-X8600BT)
Weight .......................................... 1.1 kg
Audio
Maximum power output ....... 50 W × 4
70 W × 1/2 W (for subwoo-
fer)
Continuous power output ... 22 W × 4 (50 Hz to
15 000 Hz, 5 % THD,
4
W load, both channels dri-
ven)
Load impedance ...................... 4 W to 8 W × 4
4
W to 8 W × 2 + 2 W × 1
Preout maximum output level
..................................................... 4.0 V
Equalizer (5-Band Graphic Equalizer):
Frequency .................................... 100 Hz/315 Hz/1.25 kHz/
3.15 kHz/8 kHz
Gain ................................................ ±12 dB
HPF:
Frequency .................................... 50 Hz/63 Hz/80 Hz/100 Hz/
125 Hz
Slope .............................................. –12 dB/oct
Subwoofer (mono):
Frequency .................................... 50 Hz/63 Hz/80 Hz/100 Hz/
125 Hz
Slope .............................................. –18 dB/oct
Gain ................................................ +6 dB to –24 dB
Phase ............................................ Normal/Reverse
Bass boost:
Gain ................................................ +12 dB to 0 dB
CD player
System .......................................... Compact disc audio system
Usable discs .............................. Compact disc
Signal-to-noise ratio ............... 94 dB (1 kHz) (IEC-A net-
work)
Number of channels .............. 2 (stereo)
MP3 decoding format ........... MPEG-1 & 2 Audio Layer 3
WMA decoding format ......... Ver. 7, 7.1, 8, 9, 10, 11, 12
(2 ch audio)
(Windows Media Player)
AAC decoding format ............ MPEG-4 AAC (iTunes en-
coded only) (.m4a)
(Ver. 10.7 and earlier)
WAV signal format .................. Linear PCM & MS ADPCM
(Non-compressed)
USB
USB standard specification
..................................................... USB 2.0 full speed
Maximum current supply .... 1 A
USB Class ................................... MSC (Mass Storage Class)
File system .................................. FAT12, FAT16, FAT32
MP3 decoding format ........... MPEG-1 & 2 Audio Layer 3
WMA decoding format ......... Ver. 7, 7.1, 8, 9, 10, 11, 12
(2 ch audio)
(Windows Media Player)
AAC decoding format ............ MPEG-4 AAC (iTunes en-
coded only) (.m4a)
(Ver. 10.7 and earlier)
WAV signal format .................. Linear PCM & MS ADPCM
(Non-compressed)
SD
Compatible physical format
..................................................... Version 2.00
Maximum memory capacity
..................................................... 32 GB (for SD and SDHC)
File system .................................. FAT12, FAT16, FAT32
MP3 decoding format ........... MPEG-1 & 2 Audio Layer 3
WMA decoding format ......... Ver. 7, 7.1, 8, 9, 10, 11, 12
(2 ch audio)
(Windows Media Player)
AAC decoding format ............ MPEG-4 AAC (iTunes en-
coded only) (.m4a)
(Ver. 10.7 and earlier)
WAV signal format .................. Linear PCM & MS ADPCM
(Non-compressed)
FM tuner
Frequency range ...................... 87.5 MHz to 108.0 MHz
Usable sensitivity ..................... 9 dBf (0.8 µV/75
W, mono,
S/N: 30 dB)
Signal-to-noise ratio ............... 72 dB (IEC-A network)
