Basic operations
5 4 2
1
3
1 Application name
2 PLAY/PAUSE indicator
3 S.Rtrv indicator
Appears when Sound Retriever function is on.
4 Song time (progress bar)
5 Play time indicator
Selecting a track
1 Turn LEVER.
Fast forwarding or reversing
1 Turn and hold down LEVER to the right or left.
Pausing playback
1 Press BAND/ to pause or resume.
Switching the display
Selecting the desired text information
% Press
/DISP.
Function settings
1 Press M.C. to display the main menu.
2 Turn M.C. to change the menu option
and press to select FUNCTION.
3 Turn M.C. to select the function.
Once selected, the following functions can be
adjusted.
Pause (pause)
1 Press M.C. to pause or resume.
Sound Retriever (sound retriever)
1 Press M.C. to select the desired setting.
1 —2—OFF (off)
1 is effective for low compression rates, and 2 is
effective for high compression rates.
Audio adjustments
1 Press M.C. to display the main menu.
2 Turn M.C. to change the menu option
and press to select AUDIO.
3 Turn M.C. to select the audio function.
Once selected, the following audio functions
can be adjusted.
! The cut-off frequency and output level can
be adjusted when the subwoofer output is
on.
! SLA is not available when FM is selected as
the source.
Fader/Balance (fader/balance adjustment)
1 Press M.C. to display the setting mode.
2 Press M.C. to cycle between fader (front/rear) and
balance (left/right).
3 Turn M.C. to adjust the front/rear speaker bal-
ance.
Turn
M.C. to adjust the left/right speaker balance.
Preset EQ (equalizer recall)
1 Press M.C. to display the setting mode.
2 Turn M.C. to select an equalizer curve.
Powerful —Natural—Vocal—Custom1—Cus-
tom2 —Flat—SuperBass
G.EQ (equalizer adjustment)
