You can adjust the currently selected equalizer curve
setting as desired. Adjusted equalizer curve settings
are stored in
Custom1 or Custom2.
! Custom1 can be set separately for each source.
However, each of the below combinations are set
to the same setting automatically.
! USB, iPod, SD, and App (iPhone)
! BT Audio and App (smartphone)
! Custom2 is a shared setting used in common for
all sources.
1 Press M.C. to display the setting mode.
2 Press M.C. to cycle between the following:
Equalizer band
—Equalizer level
3 Turn M.C. to select the desired setting.
Equalizer band: 100Hz —315Hz—1.25kHz—
3.15kHz —8kHz
Equalizer level: +6 to –6
Loudness (loudness)
Loudness compensates for deficiencies in the low-fre-
quency and high-frequency ranges at low volume.
1 Press M.C. to display the setting mode.
2 Press M.C. to turn loudness on or off.
3 Turn M.C. to select the desired setting.
Low (low) —Mid (mid)—High (high)
Subwoofer1 (subwoofer on/off setting)
This unit is equipped with a subwoofer output which
can be turned on or off.
1 Press M.C. to display the setting mode.
2 Press M.C. to turn subwoofer output on or off.
3 Turn M.C. to select the phase for the subwoofer
output.
Turn
M.C. to the left to select reverse phase, and
Reverse appears in the display. Turn M.C. to the
right to select normal phase, and
Normal appears
in the display.
Subwoofer2 (subwoofer adjustment)
Only frequencies lower than those in the selected
range are outputted from the subwoofer.
1 Press M.C. to display the setting mode.
2 Press M.C. to cycle between the cut-off frequency
and the output level for the subwoofer.
3 Turn M.C. to select the cut-off frequency.
50Hz —63Hz—80Hz—100Hz—125Hz
4 Turn M.C. to adjust the output level for the sub-
woofer.
+6 to
–24 is displayed as the level is increased or
decreased.
Bass Booster (bass boost)
1 Press M.C. to display the setting mode.
2 Turn M.C. to select a desired level.
0 to +6 is displayed as the level is increased or de-
creased.
HPF (high pass filter adjustment)
Use this function when wanting to listen only to high-
frequency sounds. Only frequencies higher than the
high-pass filter (HPF) cutoff are output from the
speakers.
1 Press M.C. to display the setting mode.
2 Press M.C. to turn high pass filter on or off.
3 Turn M.C. to select the cut-off frequency.
50Hz —63Hz—80Hz—100Hz—125Hz
SLA (source level adjustment)
This function prevents the volume from changing too
dramatically when the source switches.
! Settings are based on the FM volume level, which
remains unchanged.
! The MW/LW volume level can also be adjusted
with this function.
! Each of the below combinations are set to the
same setting automatically.
! USB, iPod, SD, and App (iPhone)
! BT Audio and App (smartphone)
1 Press M.C. to display the setting mode.
2 Turn M.C. to adjust the source volume.
Adjustment range: +4 to –4
Using different
entertainment displays
You can enjoy entertainment displays while lis-
tening to each sound source.
1 Press M.C. to display the main menu.
2 Turn M.C. to change the menu option
and press to select ENTERTAINMENT.
