Pioneer DEH-X8600BT - Manual (Page 10)

Black plate (10,1)
CD/CD-R/CD-RW and external
storage devices (USB, SD)
Basic operations
7 5 6 4
3 2 1
1 Bit rate/sampling frequency indicator
Shows the bit rate or sampling frequency of
the current track (file) when the compressed
audio is playing.
! When playing back VBR (variable bit
rate)-recorded AAC files, the average bit
rate value is displayed. However, de-
pending on the software used to decode
AAC files,
VBR may be displayed.
2 Folder number indicator
Shows the current folder number when play-
ing a compressed audio file.
3 Track number indicator
4 PLAY/PAUSE indicator
5 S.Rtrv indicator
Appears when Sound Retriever function is on.
6 Song time (progress bar)
7 Play time indicator
Playing a CD/CD-R/CD-RW
1 Insert the disc into the disc loading slot with the
label side up.
Ejecting a CD/CD-R/CD-RW
1 Press h (eject).
Playing songs on a USB storage device
1 Plug in the USB storage device using the USB
cable.
! Use a Pioneer USB cable to connect the USB sto-
rage device to the unit.
Stopping playback of files on a USB storage device
1 Disconnect the USB storage device.
Playing songs on an SD memory card
1 Insert an SD memory card into the SD card slot.
Insert it with the contact surface facing down,
and press on the card until it clicks and comple-
tely locks into place.
2 Press SRC/OFF to select SD as the source.
Stopping playback of files on an SD memory card
1 Press on the SD memory card until it clicks.
The SD memory card is ejected.
2 Pull out the SD memory card.
Selecting a folder
1 Press UP or DOWN.
Selecting a track
1 Turn LEVER.
Fast forwarding or reversing
1 Turn and hold down LEVER to the right or left.
! When playing compressed audio, there is no
sound during fast forward or reverse.
Returning to root folder
1 Press and hold BAND/ .
Switching between compressed audio and CD-DA
1 Press BAND/ .
Switching between playback memory devices
You can switch between playback memory devices on
USB storage devices with more than one Mass Sto-
rage Device-compatible memory device.
1 Press BAND/ .
! You can switch between up to 32 different mem-
ory devices.
MTP connection
MTP-compatible Android devices (running Android
OS 4.0 or higher) can be connected by MTP connec-
tion using the USB source. To connect an Android de-
vice, use the cable that came with the device.
! This function is not compatible with MIXTRAX.
! This function is not compatible with WAV.
! This function is not compatible with music
browse.
Notes
! Disconnect USB storage devices from the unit
when not in use.
! If there are two USB storage devices con-
nected to this unit, the device connected to
the input of the selected source is the one
that is operated.
! Disconnect communications for the USB sto-
rage device before switching to operation of
the other device.
10
En
10
Section
02 Using this unit
